5-36
Confidential
1.3.19 Continuous print test (Function code 67)
<Function>
This function is used to conduct paper feed and eject tests while printing patterns.
<Operating Procedure>
(1) Press the [6], and then the [7] in the initial state of maintenance mode. For models
without keypad, press the [▲] or [▼] to display “MAINTENANCE 67” on the LCD and
press the [OK]. “SELECT: K 100%” is displayed on the LCD.
(2) Refer to the <Print pattern> table, press the [▲] or [▼] to select the print pattern, and
press the [SET] or [OK]. “SELECT: A4” is displayed on the LCD.
(3) Refer to the <Paper size> table, press the [▲] or [▼] to select the paper size, and press
the [SET] or [OK]. “SELECT: PLAIN” is displayed on the LCD.
(4) Refer to the <Print specification> table, press the [▲] or [▼] to select the media
specification, and press the [SET] or [OK]. “SELECT: TRAY1 SX” is displayed on the
LCD.
(5) Refer to the <Print type> table, press the [▲] or [▼] to select the print type, and press
the [SET] or [OK]. “SELECT: 1PAGE” is displayed on the LCD.
(6) Refer to the <Print page> table, press the [▲] or [▼] to select the pages printing, and
press the [SET] or [OK]. For intermittent pattern printing, “SELECT: 1P/JOB” is displayed
on the LCD. For other printings, or move on to the procedure (8).
(7) Refer to the <Number of pages per job> (Only for intermittent pattern printing) table,
press the [▲] or [▼] to select the number of pages for 1 job, and press the [SET] or [OK].
(8) “PAPER FEED TEST” is displayed on the LCD, and printing test pattern starts using the
selected conditions.
(9) When you press the [X] or [Stop], test pattern printing is stopped, and the machine
returns to the initial state of maintenance mode.
<Print pattern>
*1
Up to 500 sheets in one-sided printing and 1,000 sheets in two-sided printing in the case of
job printing.
*2
Printing method and number of sheets to be printed are not selectable when the general
pattern printing is chosen.
LCD Description
SELECT: K 100% Black 100% solid print
SELECT: W 100% White 100% solid print
SELECT: K1% 1% intermittent pattern print
*1
SELECT: K5% 5% intermittent pattern print
*1
SELECT: Lattice Lattice print
SELECT: Total Total pattern print
*2
