1.3.17 Check toner cartridge (Models with cartridge sensor only)
(Function code 57)
<Function>
This function is used to acquire the toner cartridge data and check whether the country code
is right and it is compatible with the machine and capacity. Also checks the toner cartridge
version and the continuity (contact).
<Operating Procedure>
 Compatibility check
(1) Press the [5], and then the [7] in the initial state of maintenance mode. For models
without keypad, press the [▲] or [▼] to display “MAINTENANCE 57” on the LCD and
press the [OK]. “IC_ACT ALL” is displayed on the LCD.
(2) Press the [1]. For models without keypad, press the [▲] or [▼] to display “1” on the LCD
and press the [OK]. “IC_ACT ALL” is displayed on the LCD.
(3) Press the [▲] or [▼] and select the desired item from “Black”, “Main”, or “ALL” to display.
Black: Checks the cartridge sensor on the toner cartridge side.
Main: Checks the cartridge sensor on the machine side.
ALL: Checks the cartridge sensor on the toner cartridge side and machine side.
(4) Press the [Start] or [OK]. Perform the compatibility check with the machine. If it is
compatible, “IC_ACT OK” is displayed on the LCD. If it is not compatible, an error in the
<Error display> table below is displayed on the LCD.
<Error display>
 Color check
(1) Press the [5], and then the [7] in the initial state of maintenance mode. For models
without keypad, press the [▲] or [▼] to display “MAINTENANCE 57” on the LCD and
press the [OK]. “IC_ACT ALL” is displayed on the LCD.
(2) Press the [2]. For models without keypad, press the [▲] or [▼] to display “2” on the LCD
and press the [OK]. “IC_COL ALL” is displayed on the LCD.
(3) Press the [▲] or [▼] and select the desired item from “Black”, “Main”, or “ALL” to display.
Black: Checks the cartridge sensor on the toner cartridge side.
Main: Checks the cartridge sensor on the machine side.
ALL: Checks the cartridge sensor on the toner cartridge side and machine side.
(4) Press the [Start] or [OK]. Perform the compatibility check with the machine. If it is
compatible, “IC_COL OK” is displayed on the LCD. If it is not compatible, an error in the
<Error display> table above is displayed on the LCD.
LCD Description
NG0 to 99 Cartridge sensor on the machine is faulty.
Cartridge sensor PCB ASSY has to be replaced with a new one.
NG100 to 199 Could not communicate with the cartridge sensor on the toner cartridge.
Cartridge sensor contact is faulty or broken.
Toner cartridge without the cartridge sensor is installed.
NG200 to 299 Communication between the toner cartridge and cartridge sensor shows
error.
Toner cartridge may not be a genuine product.
NG300 to 399 Communication and authentication of the cartridge sensor was
performed successfully but the cartridge information was deemed
incompatible.
Toner cartridge may not be installed correctly.

Brother DCP-L2552DN Specifications

General

N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Duplex print speed (black, normal quality, A4/US Letter)	16 ppm
Processor frequency	600 MHz
Card reader integrated	No
Sound pressure level (standby)	30 dB
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	44 dB
Cabling technology	10/100Base-T(X)
Security algorithms	SMTP-AUTH, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, SMTP Client, IPP/IPPS, FTP Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print), SNTP Client
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, SMTP Client, FTP Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, Web Services (Print)
Direct printing	-
Display	LCD
Control type	Buttons
Product color	Black
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	34 cpm
Package depth	517 mm
Package width	580 mm
Package height	434 mm
Package weight	14700 g
Included cartridge capacity (black)	1200 pages
Scan to	E-mail, FTP, File, Image, OCR
Scan drivers	SANE, TWAIN
Grayscale levels	256
Output color depth	24 bit
Output grayscale depth	8 bit
Maximum scan resolution	19200 x 19200 DPI
Recommended monthly print volume	2000 pages
PCL fonts	94
Printer fonts	PCL, PostScript
Maximum duty cycle	15000 pages per month
Recommended duty cycle	0 - 2000 pages per month
Number of PostScript fonts	66
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7, PostScript 3
Total input capacity	250 sheets
Total output capacity	120 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	50 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 230 g/m²
Auto Document Feeder (ADF) media weight	64 - 105 g/m²
Power consumption (max)	475 W
Power consumption (off)	0.03 W
Power consumption (sleep)	6.2 W
Power consumption (standby)	42 W
Power consumption (printing)	260 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	1348 kWh/week
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	318.5 mm
Weight	11600 g
