Page #610 background image
Home > Routine Maintenance > Replace Periodic Maintenance Parts
Replace Periodic Maintenance Parts
Replace the following parts regularly to maintain print quality. The parts listed below must be replaced after
printing approximately 50,000 pages
1
for the PF Kit MP and 200,000 pages
1
for the PF Kit for the Paper Tray
2
,
PF Kit for the Optional Tray(s), Fuser Unit, and Laser Unit.
Contact Brother Customer Service or a Brother Authorized Service Center when the following message appears
on the LCD:
LCD Message Description
Replace Fuser
3
Replace the Fuser Unit.
Replace Laser
3
Replace the Laser Unit.
Replace PF Kit 1
3
Replace the Paper Feeding Kit for the Paper Tray.
Replace PF Kit 2
3 4
Replace the Paper Feeding Kit for the Optional Tray(s).
Replace PF Kit MP
3
Replace the Paper Feeding Kit for the Multi-purpose Tray.
Related Information
Routine Maintenance
1
Letter or A4 size 1-sided pages
2
(DCP-L5500DN/DCP-L5600DN/DCP-L5650DN/MFC-L5700DW/MFC-L5705DW/MFC-L5800DW/MFC-L5850DW/MFC-L5900DW) After
December 2016, you must update your machine's firmware. Go to your model's Downloads page on the Brother Solution Center at
support.brother.com.
3
Replacement frequency depends on the complexity of printed pages, percentage of coverage, and the type of media used.
4
If you use the Optional Tray(s) with your machine, this message will appear on the LCD. When the machine has multiple Optional Trays, the
machine displays messages using numbers corresponding to each Optional Tray.
603

Table of Contents

Other manuals for Brother DCP-L5650DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother DCP-L5650DN and is the answer not in the manual?

Brother DCP-L5650DN Specifications

General IconGeneral
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)7.2 s
Print speed (black, normal quality, A4/US Letter)42 ppm
Copier resize25 - 400 %
Maximum copy resolution- DPI
N-in-1 copy function (N=)2, 4
Copy speed (black, normal quality, A4)42 cpm
Scan toCloud, E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scanner typeFlatbed scanner
Scan speed (black)28 ppm
Scan speed (color)20 ppm
Image formats supportedBMP, JPG, PNG, TIF
Maximum scan resolution19200 x 19200 DPI
Duplex scan speed (black)56 ppm
Duplex scan speed (color)34 ppm
Document formats supportedDOCX, PDF, PPTX, TXT, XML, XPS
DisplayLCD
Control typeTouch
Product colorBlack
Display diagonal3.7 \
Market positioningBusiness
Card reader integratedNo
Sound power level (standby)35 dB
Sound pressure level (printing)55 dB
Digital sender-
Maximum duty cycle50000 pages per month
Recommended duty cycle0 - 3500 pages per month
Page description languagesBR-Script 3, Epson FX, IBM ProPrinter, PCL 6, PDF 1.7
Security algorithms802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, HTTPS, IPPS, PEAP, SMTP-AUTH, SNMP, SSL/TLS
Online services supportedDropbox, Evernote, Facebook, Flickr, Google Drive, OneDrive, OneNote, Picasa
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP
Supported network protocols (IPv6)NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, LDAP, Web Services (Print/Scan)
Total input capacity250 sheets
Total output capacity150 sheets
Multi-Purpose tray input capacity50 sheets
Auto document feeder (ADF) input capacity70 sheets
Envelopes sizes6 3/4, 7 3/4, 9, 10
Paper tray media typesBond paper, Envelopes, Recycled paper
Non-ISO print media sizesExecutive
ISO A-series sizes (A0...A9)A4, A5, A6
Multi-purpose tray media typesEnvelopes, Letterhead
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight (imperial)16 - 53 lbs
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantity1
Power consumption (off)0.03 W
Power consumption (ready)36 W
Power consumption (sleep)8.4 W
Power consumption (average operating)630 W
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)20 - 80 %
Package depth525.78 mm
Package width599.44 mm
Package height629.92 mm
Package weight20638.453 g
Weight and Dimensions IconWeight and Dimensions
Depth426.72 mm
Width495.3 mm
Height485.14 mm
