Brother DCP-L5650DN User Manual

Web Based Management
A standard Web Browser can be used to manage your machine using the Hyper Text Transfer Protocol (HTTP)
or Hyper Text Transfer Protocol over Secure Socket Layer (HTTPS). You can perform the function listed or get
the following information from a machine on your network using a web browser:
• Machine status information
• Change Fax configuration items, such as General Setup, Address Book settings and Remote Fax (For
models with facsimile function)
• Change network settings, such as TCP/IP information
• Configure Gigabit Ethernet and Jumbo Frame
• Configure Secure Function Lock
• Configure Store Print Log to Network
• Configure Scan to FTP
• Configure Scan to Network
• Configure LDAP (available for certain models)
• Software version information of the machine and print server
• Change network and machine configuration details
In order to use Web Based Management, you must use the TCP/IP protocol on your network and have a
valid IP address programmed into the print server and your computer.
Web Services
The Web Services protocol enables Windows Vista, Windows 7, or Windows 8 users to install the drivers used
for printing and scanning by using the machine icon in the Network folder. Web Services also lets you check the
current status of the machine from your computer.
WEP
Wired Equivalent Privacy (WEP) is one of the encryption methods used in a wireless network. When using WEP,
the data is transmitted and received with a secure key.
Wi-Fi Direct
®
Wi-Fi Direct is one of the wireless configuration methods developed by the Wi-Fi Alliance
®
. This type of
connection is a Wi-Fi
®
standard that allows devices to connect with each other without a wireless access point,
using secured method.
WINS
Windows Internet Name Service (WINS) is an information-providing service for NetBIOS name resolution. It
consolidates an IP address and a NetBIOS name that is in the local network.
WINS Server
Windows Internet Name Service (WINS) Server maps IP addresses to computer names (NetBIOS names) in a
Windows network.
Home > Glossary
722

Brother DCP-L5650DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	42 cpm
Scan to	Cloud, E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scanner type	Flatbed scanner
Scan speed (black)	28 ppm
Scan speed (color)	20 ppm
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (black)	56 ppm
Duplex scan speed (color)	34 ppm
Document formats supported	DOCX, PDF, PPTX, TXT, XML, XPS
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.7 \
Market positioning	Business
Card reader integrated	No
Sound power level (standby)	35 dB
Sound pressure level (printing)	55 dB
Digital sender	-
Maximum duty cycle	50000 pages per month
Recommended duty cycle	0 - 3500 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6, PDF 1.7
Security algorithms	802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, HTTPS, IPPS, PEAP, SMTP-AUTH, SNMP, SSL/TLS
Online services supported	Dropbox, Evernote, Facebook, Flickr, Google Drive, OneDrive, OneNote, Picasa
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, LDAP, Web Services (Print/Scan)
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	70 sheets
Envelopes sizes	6 3/4, 7 3/4, 9, 10
Paper tray media types	Bond paper, Envelopes, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Envelopes, Letterhead
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight (imperial)	16 - 53 lbs
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (off)	0.03 W
Power consumption (ready)	36 W
Power consumption (sleep)	8.4 W
Power consumption (average operating)	630 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	525.78 mm
Package width	599.44 mm
Package height	629.92 mm
Package weight	20638.453 g

Weight and Dimensions

Depth	426.72 mm
Width	495.3 mm
Height	485.14 mm
