4.2.3 No paper is fed from TT
<User Check>
• Check that the paper is set in the paper tray correctly.
• Check that there is not too much paper set in the paper tray.
• Flip over the paper in the paper tray or rotate the paper 180°.
• Check that the thickness of the paper is 60 to 120 g/m
2
(paper tray 2 to 5).
• Check that the MP tray, LT or TT are not set as the paper tray.
• Flip through the paper and reset it in the paper tray.
• Clean the paper pick up roller.
• Install the latest main firmware.
• Replace the relay AC cord.
• Turn the power switch of TT OFF and then back ON again.
Step Cause Remedy
1
Dirt on a paper dust cleaning
roller of the paper tray
Clean the appropriate paper dust cleaning
roller. (Refer to Fig. 2-9.)
2
Attachment failure of a roller
holder ASSY
Reattach the appropriate roller holder ASSY
correctly.
3
Connection failure of the TT
motor harness
Reconnect the TT motor harness.
4
Connection failure of a TT paper
feed sensor harness
Reconnect the appropriate TT paper feed
sensor harness.
5
Connection failure of a TT relay
PCB harness
Reconnect the appropriate TT relay PCB
harness.
6
Connection failure of the TT
control PCB harness
Reconnect the TT control PCB harness.
7
Connection failure of the TT low-
voltage power supply PCB
harness
Reconnect the TT low-voltage power supply
PCB harness.
8
Connection failure of a TT
release clutch harness
Reconnect the appropriate TT release clutch
harness.
9
Connection failure of a TT
pickup clutch harness
Reconnect the appropriate TT pickup clutch
harness.
10
Connection failure of a TT jam
sensor harness
Reconnect the appropriate TT jam sensor
harness.
11
A TT paper empty actuator
coming off
Reattach the appropriate TT paper empty
actuator.
12
Abrasion of a paper pick up
roller
Replace the appropriate PF kit.
13 A TT release clutch failure Replace the appropriate TT release clutch.
14 A TT pickup clutch failure Replace the appropriate TT pickup clutch.
15
A TT paper empty sensor failure Replace the appropriate TT paper empty
sensor PCB ASSY.
16 TT balance sensor L/R failure Replace the TT balance sensor L/R.
17
A TT jam sensor failure Replace the appropriate TT jam sensor PCB
ASSY.
18 Damaged a plate gear Replace the appropriate plate gear.
19 Damaged an LT/TT connector Replace the appropriate LT/TT connector.
20 TT motor failure Replace the TT motor.
21 A TT relay PCB failure Replace the appropriate TT relay PCB ASSY.
22 TT control PCB failure Replace the TT control PCB ASSY.
23 Panel PCB failure Replace the panel PCB ASSY.
24
TT low-voltage power supply
PCB failure
Replace the TT low-voltage power supply PCB
ASSY.
25 Main PCB failure Replace the main PCB ASSY.
