Brother HL-L5100DN Service Manual

5-25
Confidential
1.3.11 Adjust printable range for each speed level
(Full speed / Half speed for thick paper / Quiet Mode) (function code: 46)
<Function>
This function is to adjust the printing position in horizontal / vertical direction when it's
misaligned on Full speed, Half speed for thick paper, or Quiet Mode.
Position can be adjusted in 11 steps from -0.5% to 0.5% (Printing width gets smaller when
the value is negative).
<Operating Procedure>
Non touch panel models
(1) Press the [▲] or [▼] key in the initial
state of maintenance mode to display
"MAINTENANCE 46" on the LCD, and
press the [OK] key. "1.PrtSzAdj
Nomal" is displayed on the LCD.
(2) Press the [▲] or [▼] key to display
desired speed on the LCD.
• Full speed → "1.PrtSzAdj Nomal"
• Half speed for thick paper →
"2.PrtSzAdj THalf"
• Quiet Mode → "3.PrtSzAdj QHalf"
Press the [OK] key. "*.1 *:Main" is
displayed on the LCD.
Selected speed is displayed for "*".
(3) Press the [▲] or [▼] key to display
"*.3 *:Print" on the LCD, and press the
[OK] key. "PRINTING" is displayed on
the LCD, and the print adjustment test
pattern (refer to the next page) is
printed on a sheet of paper.
(4) Adjust the line so that the width is
10mm in horizontal / vertical direction.
Press the [▲] or [▼] key to display
desired direction on the LCD.
• Horizontal direction → "*.1 *:Main"
• Vertical direction → "*.2 *:Sub"
Press the [OK] key. "0.0 %" is displayed
on the LCD.
(5) To make the print width smaller, press
the [▼] key to decrease the value.
Press the [OK] key after adjusting the
value.
(6) Press the [X] key to return the
machine to the initial state of
maintenance mode after adjusting the
value.
Touch panel models
(1) Press the [4], and then the [6] key in
the initial state of maintenance mode.
"1.PrtSzAdj Nomal" is displayed on
the LCD.
(2) Press the [
˄ ] or [ ˅ ] key to display
desired speed on the LCD.
• Full speed → "1.PrtSzAdj Nomal"
• Half speed for thick paper →
"2.PrtSzAdj THalf"
• Quiet Mode → "3.PrtSzAdj QHalf"
Press the [Mono] key. "*.1 *:Main" is
displayed on the LCD.
Selected speed is displayed for "*".
(3) Press the [
˄ ] or [ ˅ ] key to display "*.3
*:Print" on the LCD, and press the
[Mono] key. "PRINTING" is displayed
on the LCD, and the print adjustment
test pattern (refer to the next page) is
printed on a sheet of paper.
(4) Adjust the line so that the width is
10mm in horizontal / vertical direction.
Press the [
˄ ] or [ ˅ ] key to display
desired direction on the LCD.
• Horizontal direction → "*.1 *:Main"
• Vertical direction → "*.2 *:Sub"
Press the [Mono] key. "0.0 %" is
displayed on the LCD.
(5) To make the print width smaller, press
the [
˅ ] key to decrease the value.
Press the [Mono] key after adjusting
the value.
(6) Press the [X] key to return the
machine to the initial state of
maintenance mode after adjusting the
value.

Brother HL-L5100DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
PCL fonts	66
Printer fonts	Bitmap, PostScript
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	0 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, Microsoft XPS, PCL 6, PDF 1.7, PostScript 3
Display	LCD
Certification	Nordic Swan
Product color	Graphite
Market positioning	-
Display number of lines	1 lines
AC input frequency	50 - 60 Hz
Power consumption (off)	0.04 W
Power consumption (standby)	32 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.763 kWh/week
Processor model	A9
Processor family	ARM Cortex
Maximum internal memory	- MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	52 dB
Sound pressure level (quiet mode)	50 dB
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Duplex media weight (imperial)	60 - 120 lbs
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Cabling technology	10/100Base-T(X)
Security algorithms	802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSEC, PEAP, SMTP-AUTH, SNMP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c/v3, ICMP, Web Services (Print), CIFS Client, SNTP Client
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c, ICMPv6, Web Services (Print), CIFS Client, SNTP Client
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package depth	450 mm
Package width	485 mm
Package height	377 mm
Package weight	13000 g
Sustainability certificates	Blue Angel, ENERGY STAR
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Email protocols	SMTP
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	388 mm
Width	373 mm
Height	255 mm
