5-13
Confidential
1.3.6 Display software version (function code: 25)
<Function>
This function is used to check the version information of the firmwares and programs, or
check sum information.
<Operating Procedure>
*1
How to display the check sum information
You can check the check sum information by pressing the [OK] key while each version
is displayed. When the [OK] key is pressed again, the LCD returns to the version
display.
*2
(P) indicates that the firmware supports PCL/PS.
*3
There are two types of check sum information that can be checked with this function.
This function checks if the two types of check sum information match each other.
When the [OK] key is pressed while "ROM Check Sum" is displayed, check is
automatically conducted for each ROM of each software part. When the check sum
matches, "OK" is displayed on the LCD. When all ROMs result in OK, "ROM Check
Sum OK" is displayed at the end, and the operation is finished. When the check sum
of any ROM does not match, "NG" is displayed, and the display stops.
*4
This is displayed on the LCD even no firmware is installed.
*5
Displayed only for font firmware support model.
Non touch panel models
(1) Press the [▲] or [▼] key in the initial
state of maintenance mode to display
"MAINTENANCE 25" on the LCD, and
press the [OK] key. "MAIN:Ver*.** (#)"
is displayed on the LCD.
(2) Pressing the [Go], [▲] or [▼] key
changes the display item as shown in
the table below.
(3) Press the [X] key, and the machine
returns to the initial state of
maintenance mode.
Touch panel models
(1) Press the [2], and then the [5] key in
the initial state of maintenance mode.
"MAIN:Ver*.** (#)" is displayed on the
LCD.
(2) Pressing the [▲], [
˄
], or [Mono] key
changes the display to the next item.
(3) When you press the [X] key, this
operation is finished and the machine
returns to the initial state of
maintenance mode.
LCD Description
MAIN: Ver1.00 (A)
*1
Main firmware version information
((A): Revision information)
SUB1 : Ver1.00 (P)
*1
Sub firmware version information
((P): Identifier for PCL/PS)
*2
ENG: Ver.1.00 Do not refer to this item because it has nothing to do with DL.
NET : Ver1.00 Network program version information
MX :Ver1.00 MX firmware version information
TT :Ver1.00 TT firmware version information
LT1 :Ver1.00 LT1 firmware version information
LT2 :Ver1.00 LT2 firmware version information
LT3 :Ver1.00 LT3 firmware version information
B0608071049:5708
*1
Boot program creation date
U0612271600:7B0A
*1
Main firmware creation date
D----------:----
*4
Demo firmware data creation date
F0612312359:1234
*5
Font firmware creation date
P0612271602:BD40
*1
Sub firmware (PCL/PS) creation date
ROM Check Sum Check sum self-diagnosis function
*3
To Next Page
