5-28
Confidential
1.3.13 Continuous print test (function code: 67)
<Function>
This function is used to conduct paper feed and eject tests while printing patterns.
<Operating Procedure>
Non touch panel models
(1) Press the [▲] or [▼] key in the initial
state of maintenance mode to display
"MAINTENANCE 67" on the LCD, and
press the [OK] key. "SELECT: K
100%" is displayed on the LCD.
(2) Refer to the <Print pattern> table,
press the [▲] or [▼] key to select the
print pattern, and press the [OK] key.
For total pattern printing, proceed to
the procedure (9). Otherwise,
"SELECT: A4" is displayed on the LCD.
(3) Refer to the <Paper size> table, press
the [▲] or [▼] key to select the paper
size, and press the [OK] key. "SELECT:
PLAIN" is displayed on the LCD.
(4) Refer to the <Print specification>
table, press the [▲] or [▼] key to
select the media specification, and
press the [OK] key. "SELECT: TRAY1
SX" is displayed on the LCD.
(5) Refer to the <Print type> table, press
the [▲] or [▼] key to select the print
type, and press the [OK] key. "SELECT:
STD" is displayed on the LCD.
(6) Refer to the <Output tray> table, press
the [▲] or [▼] key to select the output
tray, and press the [OK] key. "SELECT:
1PAGE" is displayed on the LCD.
(MX supported models only)
(7) Refer to the <Print page> table, press the
[▲] or [▼] key to select the pages printing,
and press the [OK] key. For intermittent
pattern printing, "SELECT: 1P/JOB" is
displayed on the LCD. For other printings,
or move on to the procedure (9).
(8) Refer to the <Number of pages per
job> table, press the [▲] or [▼] key to
select the number of pages for 1 job,
and press the [OK] key. (Only for
intermittent pattern printing)
(9) "PAPER FEED TEST" is displayed on
the LCD, and printing test pattern
starts using the selected conditions.
(10) When you press the [X] key, test pattern
printing is stopped, and the machine returns
to the initial state of maintenance mode.
Touch panel models
(1) Press the [6], and then the [7] key in
the initial state of maintenance mode.
"SELECT: K 100%" is displayed on
the LCD.
(2) Refer to the <Print pattern> table,
press the [
˄
] or [
˅
] key to select the
print pattern, and press the [SET] key.
For total pattern printing, proceed to
the procedure (9). Otherwise,
"SELECT: A4" is displayed on the LCD.
(3)
Refer to the <Paper size> table, press
the [
˄
] or [
˅
] key to select the paper
size, and press the [SET] key. "SELECT:
PLAIN" is displayed on the LCD.
(4) Refer to the <Print specification>
table, press the [
˄
] or [
˅
] key to select
the media specification, and press the
[SET] key. "SELECT: TRAY1 SX" is
displayed on the LCD.
(5) Refer to the <Print type> table, press the
[
˄
] or [
˅
] key to select the print type, and
press the [SET] key. "SELECT: STD" is
displayed on the LCD.
(6) Refer to the <Output tray> table, press
the [
˄
] or [
˅
] key to select the output
tray, and press the [SET] key. "SELECT:
1PAGE" is displayed on the LCD.
(MX supported models only)
(7) Refer to the <Print page> table, press
the [
˄
] or [
˅
] key to select the pages
printing, and press the [SET] key. For
intermittent pattern printing, "SELECT:
1P" is displayed on the LCD. For other
printings, or move on to the procedure
(9).
(8) Refer to the <Number of pages per
job> table, press the [
˄
] or [
˅
] key to
select the number of pages for 1 job,
and press the [SET] key. (Only for
intermittent pattern printing)
(9) "PAPER FEED TEST" is displayed on
the LCD, and printing test pattern
starts using the selected conditions.
(10) When you press the [X] key, test
pattern printing is stopped and the
machine returns to the initial state of
maintenance mode.
To Next Page
