Brother HL-L5100DN Service Manual

2-8
Confidential
2.4 Block Diagram
Fig. 2-4
Main PCB
Eject stack sensor
Touch panel models only
External temperature/humidity sensor
Internal temperature sensor
Eject motor
Paper feed motor
T1: Models with 520-sheet only
Erase lamp PCB
Back cover/duplex
tray sensor
Develop release clutch
MP solenoid
T1 pickup clutch
Registration clutch
Front cover sensor
Relay front PCB
New toner
sensor
Toner amount
detection sensor
PCB (light reception)
Laser unit
LD PCB
BD sensor Polygon motor
Toner amount
detection sensor
PCB (light emission)
LT
LT control PCB
LT release clutch
LT pickup clutch
LT paper empty
sensor PCB
LT paper feed
sensor PCB
High-voltage
power supply PCB
Registration front/
rear sensor PCB
MP paper empty
sensor PCB
T1 paper feed
sensor PCB
TT
control
PCB
MX
MX 1bin switching solenoid
MX jam upper sensor
MX jam lower sensor
MX 2bin detection sensor
MX 4bin detection sensor
MX motor
MX 2bin switching solenoid
MX 3bin switching solenoid
MX switching solenoid
MX
control
PCB
MX
relay
PCB
MX 1bin stack sensor PCB
MX 2bin stack sensor PCB
MX 3bin stack sensor PCB
MX 4bin stack sensor PCB
MX back cover sensor
Wireless LAN PCBWLAN models only
Paper empty sensor PCB
Models with 520-sheet T1 and HL-5580D/5585D only
Center thermistor
Side thermistor
Heater
Low-voltage
power supply PCB
Eject sensor PCB
Fuser unit
Panel PCB
Touch panel models only
NFC models only
Panel PCB
Non touch panel
models only
LCD
Color LCD
NFC
LCD panel ASSY
LCD relay PCB
Key PCB
TT
T2TT
relay
PCB
T3TT
relay
PCB
T4TT
relay
PCB
T5TT
relay
PCB
T2TT pickup clutch
T2TT jam sensor PCB
T2TT paper feed sensor PCB
T2TT paper empty sensor PCB
T3TT pickup clutch
T3TT release clutch
T3TT jam sensor PCB
T3TT paper feed sensor PCB
T3TT paper empty sensor PCB
T4TT pickup clutch
T4TT release clutch
T4TT jam sensor PCB
T4TT paper feed sensor PCB
T4TT paper empty sensor PCB
T5TT pickup clutch
T5TT release clutch
T5TT jam sensor PCB
TT motor
TT balance sensor L
TT fan
Low-voltage Power Supply PCB
Relay connector
TT balance sensor R
Relay connector
T5TT paper feed sensor PCB
T5TT paper empty sensor PCB
Fuser fan
Models with 520-sheet only

Brother HL-L5100DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
PCL fonts	66
Printer fonts	Bitmap, PostScript
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	0 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, Microsoft XPS, PCL 6, PDF 1.7, PostScript 3
Display	LCD
Certification	Nordic Swan
Product color	Graphite
Market positioning	-
Display number of lines	1 lines
AC input frequency	50 - 60 Hz
Power consumption (off)	0.04 W
Power consumption (standby)	32 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.763 kWh/week
Processor model	A9
Processor family	ARM Cortex
Maximum internal memory	- MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	52 dB
Sound pressure level (quiet mode)	50 dB
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Duplex media weight (imperial)	60 - 120 lbs
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Cabling technology	10/100Base-T(X)
Security algorithms	802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSEC, PEAP, SMTP-AUTH, SNMP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c/v3, ICMP, Web Services (Print), CIFS Client, SNTP Client
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c, ICMPv6, Web Services (Print), CIFS Client, SNTP Client
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package depth	450 mm
Package width	485 mm
Package height	377 mm
Package weight	13000 g
Sustainability certificates	Blue Angel, ENERGY STAR
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Email protocols	SMTP
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	388 mm
Width	373 mm
Height	255 mm
