3-21

Confidential

5 Bottom side of the top cover ASSY (Non touch panel models)

Harness colors are subject to change for some reason.

LCD FPC

Panel PCB ASSY

Panel harness ASSY

(RD, BK, YW, GR, BL, WH)
