Brother HL-L5100DN Service Manual

5-18
Confidential
Change the status of the registration rear sensor from
No paper to Paper set.
The registration clutch remains ON
for the specified time.
Change the status of the new toner sensor from
Not pressed to Pressed.
The develop clutch remains ON for the
specified time.
Erase Lamp is ON (keep the develop
clutch ON until the new toner sensor
gets pressed)
Change the status of the MX 1bin stack sensor from
Not full to Full.
MX solenoid is moved to MX 1bin
side.
Change the status of the MX 2bin stack sensor from
Not full to Full.
MX solenoid is moved to MX 2bin
side.
Change the status of the MX 3bin stack sensor from
Not full to Full.
MX solenoid is moved to MX 3bin
side.
Change the status of the MX 1bin stack sensor from
Full to Not full.
MX solenoid is moved to the side
which does not eject paper to the
MX 1bin.
Change the status of the MX 2bin stack sensor from
Full to Not full.
MX solenoid is moved to the side
which does not eject paper to the
MX 2bin.
Change the status of the MX 3bin stack sensor from
Full to Not full.
MX solenoid is moved to the side
which does not eject paper to the
MX 3bin.
Change the status of the
T2TT paper feed sensor from
TT paper tray 2 open to TT paper tray 2 closed.
The T2TT pickup clutch remains
ON for the specified time.
Change the status of the
T3TT paper feed sensor from
TT paper tray 3 open to TT paper tray 3 closed.
The T3TT pickup clutch remains
ON for the specified time.
Change the status of the
T4TT paper feed sensor from
TT paper tray 4 open to TT paper tray 4 closed.
The T4TT pickup clutch remains
ON for the specified time.
Change the status of the
T5TT paper feed sensor from
TT paper tray 5 open to TT paper tray 5 closed.
The T5TT pickup clutch remains ON
for the specified time.
Change the status of the T3TT paper empty sensor from
No paper to Paper set.
The T3TT release clutch remains
ON for the specified time.
Change the status of the T4TT paper empty sensor from
No paper to Paper set.
The T4TT release clutch remains
ON for the specified time.
Change the status of the T5TT paper empty sensor from
No paper to Paper set.
The T5TT release clutch remains
ON for the specified time.
Note:
• LCD display changes by activating the sensors above. However, it does not affect to the
operation of the solenoid and clutch. If the sensors to operate the solenoid and clutch are
faulty, they are inoperable.
Sensor operation Solenoid/clutch operation

Brother HL-L5100DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
PCL fonts	66
Printer fonts	Bitmap, PostScript
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	0 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, Microsoft XPS, PCL 6, PDF 1.7, PostScript 3
Display	LCD
Certification	Nordic Swan
Product color	Graphite
Market positioning	-
Display number of lines	1 lines
AC input frequency	50 - 60 Hz
Power consumption (off)	0.04 W
Power consumption (standby)	32 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.763 kWh/week
Processor model	A9
Processor family	ARM Cortex
Maximum internal memory	- MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	52 dB
Sound pressure level (quiet mode)	50 dB
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Duplex media weight (imperial)	60 - 120 lbs
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Cabling technology	10/100Base-T(X)
Security algorithms	802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSEC, PEAP, SMTP-AUTH, SNMP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c/v3, ICMP, Web Services (Print), CIFS Client, SNTP Client
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c, ICMPv6, Web Services (Print), CIFS Client, SNTP Client
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package depth	450 mm
Package width	485 mm
Package height	377 mm
Package weight	13000 g
Sustainability certificates	Blue Angel, ENERGY STAR
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Email protocols	SMTP
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	388 mm
Width	373 mm
Height	255 mm
