Brother JS2135 User Manual

14
—————
——————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
1
Lower threading (for
models equipped with a
quick-set bobbin)
Install the bobbin wound with thread.
This feature is only available on certain models.
1
Follow steps 1 to 4 from “Lower
threading” on page 13.
2
While lightly holding down the bobbin
with your right hand as shown, guide the
thread through the slit (1 and 2). Then,
pull the thread toward you to cut it with
the cutter (3).
• At this time, check that the bobbin easily
rotates counterclockwise.
1 Slit
2 Cutter (Cut the thread with the cutter.)
Note
● If the thread is not correctly inserted through
the tension-adjusting spring of the bobbin
case, it may cause incorrect thread tension.
1 Tension-adjusting spring
3
Replace the bobbin cover. Put the
projection into the race retainer groove
and push closed.
1 Groove
2 Projection
• Start sewing after threading the lower and
upper thread. When sewing gathers or darts,
you can draw up the lower thread by hand so
that some thread will be left over. Refer to the
steps in “Drawing up the lower thread”
(page 17).
1
2
2
3
1
1
1
2

Brother JS2135 Specifications

General

Type	-
Display	No
Handle(s)	Yes
Sewing speed	750
Stitch width	5 mm
Product color	Green, White
Stitch length	4 mm
Buttonhole type	4 Step
Number of programs	35
Number of button holes	1
Sewing machine functions	Embroidery, Overlock, Sewing
Number of stitch patterns	14
Sewing machine accessories included	Button sewing foot, Buttonhole foot, Zigzag foot, Zipper foot

Weight and Dimensions

Depth	392 mm
Width	148 mm
Height	308 mm
Weight	4900 g
