Brother MFC-8480DN - B/W Laser - All-in-One Parts Reference List

List9(SCANNER)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARKS
1 LP2357001 1
A
LFB UNIT ASSY
(
SP
)

1-1 LG2239001 1 PHOTO INTERRUPTER
1-2 LF9629001 1 FFC CABLE ASS
Y
1-3 LE8632001 1 SCANNING MOTOR FB
1-4 LF9637001 1 PULLEY ASS
Y
1-5 LE8640001 1 PULLEY SPRING
1-6 LF2037001 1 CCD MODULE
(
SP
)

1-7 LE8642001 1 BELT
1-8 LF9641001 1 TOP COVER ASSY
1-8-1 LF2004001 1 LOCK LEVER ASS
Y
1-8-2 LE8649001 1 LOCK LEVER B
1-8-3 UF5034001 3 TAPTITE, B 3X6
1-9 08741121
6
6 TAPTITE, CUP B M4X12
1-10 LE2861001 4 TAPTITE, PAN B M3X8
1-11 0A430060
6
2 SCREW, PAN
(
S/P WASHER
)
M3X6
1-12 UF5034001 2 TAPTITE, B 3X6
2 08741201
6
2 TAPTITE, CUP B M4X20
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61
DCP8080DN/DCP8085DN/MFC8480DN/
MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 18 -

Brother MFC-8480DN - B/W Laser - All-in-One Specifications

General

Printer Type	B/W Laser
Functions	Print, Copy, Scan, Fax
Scan Resolution	Up to 19200 x 19200 dpi (interpolated)
Automatic Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet
Paper Input Capacity	250 sheets
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Print Speed	32 ppm
Copy Resolution	1200 x 600 dpi
Scan Type	Flatbed, ADF
Max Paper Size	Legal (8.5 in x 14 in)
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 32 cpm
Dimensions	531 mm x 451 mm x 475 mm
