Brother MFC-8480DN - B/W Laser - All-in-One Parts Reference List

LIST13(PCB)
REF No. CODE Q'TY DESCRIPTION RECOMMEND SYMBO
L
REMARKS
1 LT0755001 1 MAIN PCB ASSY, DCP8080DN

B53K992
1 LT0839001 1 MAIN PCB ASSY, DCP8085DN EXCEPT FOR CHN

B53K992
1 LT0754001 1 MAIN PCB ASSY, MFC8480DN FOR US/CAN

B53K992
1 LT0753001 1 MAIN PCB ASSY, MFC8680DN

B53K992
1 LT0753004 1 MAIN PCB ASSY, MFC8880DN/MFC8881DNHY EXCEPT FOR CHN

B53K992
1 LT0673001 1 MAIN PCB ASSY, MFC8890DW FOR US/CAN

B53K992
1 LT0754004 1 MAIN PCB ASSY, MFC8480DN FOR ARG/CHL/BRA

B53K992
1 LT0673004 1 MAIN PCB ASSY, MFC8890DW EXCEPT FOR US/CAN

B53K992
1 LT0839020 1 MAIN PCB ASSY, DCP8085DN FOR CHN

B53K992
1 LT0753020 1 MAIN PCB ASSY, MFC8880DN FOR CHN

B53K992
2 LT0867001 1 NCU PCB ASSY, MFC8480DN/MFC8680DN/MFC8890DW FOR US

B57T013 CHG
2 LT0867003 1 NCU PCB ASSY, MFC8480DN/MFC8890DW FOR CAN

B57T013 CHG
2 LG5923054 1 NCU PCB ASSY, MFC8880DN/MFC8890DW FOR GER/AUS/POL/EEU

B53K786
2 LG5923065 1 NCU PCB ASSY, MFC8880DN/MFC8881DNHY/MFC8890DW FOR
UK/FRA/BEL/NLD/ITA/TUR/RUS/PND/IBR

B53K786
2 LG5923056 1 NCU PCB ASSY, MFC8880DN/MFC8890DW FOR CHE

B53K786
2 LG6190005 1 NCU PCB ASSY, MFC8480DN/MFC8890CW FOR ARG/CHL,
MFC8880DN FOR CHN/PHL/ASA/IND

B53K786
2 LG6872003 1 NCU PCB ASSY, MFC8880DN FOR GUL

B53K896
2 LG6190006 1 NCU PCB ASSY, MFC8480DN/8890DW FOR BRA

B53K786
2 LG6190009 1 NCU PCB ASSY, MFC8880DN FOR KOR

B53K786
2 LG6198003 1 NCU PCB ASSY, MFC8880DN/MFC8890CW FOR ARL/NZ

B53K786
3 LV0292001 1 PS PCB UNIT, DCP8080DN/DCP8085DN/MFC8480DN/MFC8680DN/
MFC8890DW FOR US/CAN/BRA
3 LV0328001 1 PS PCB UNIT, DCP8080DN/DCP8085DN/MFC8480DN/MFC8880DN/
MFC8881DNHY/MFC8890DW FOR GER/UK/FRA/BEL/NLD/CHE/AUS/
ITA/PHL/TUR/ ARG/CHL/POL/ASA/GUL/ARL/NZ/PND/IBR/EEU
3 LU7519001 1 PS PCB UNIT, DCP8085DN/MFC8880DN FOR CHN/IND/RUS
3 LV0437001 1 PS PCB UNIT, MFC8880DN FOR KOR
4 LJ9978001 1 HIGH-VOLTAGE PS PCB ASSY
5 LM5867001 4 TAPTITE CUP S M3X6 SR
6 LG5921001 1 BATTERY ASSY
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61
DCP8080DN/DCP8085DN/MFC8480DN/
MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 26 -

Brother MFC-8480DN - B/W Laser - All-in-One Specifications

General

Printer Type	B/W Laser
Functions	Print, Copy, Scan, Fax
Scan Resolution	Up to 19200 x 19200 dpi (interpolated)
Automatic Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet
Paper Input Capacity	250 sheets
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Print Speed	32 ppm
Copy Resolution	1200 x 600 dpi
Scan Type	Flatbed, ADF
Max Paper Size	Legal (8.5 in x 14 in)
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 32 cpm
Dimensions	531 mm x 451 mm x 475 mm
