3
c Connect the telephone line cord.
Connect one end of the telephone line cord to
the jack marked LINE on the machine.
Carefully guide the telephone line cord into the
cable channel and out the back of the machine.
Connect the other end to a modular wall jack.
d Gently close the scanner cover using the finger
holds on each side.
CAUTION
Be careful not to pinch your fingers when you
close the scanner cover.
Always use the finger holds provided on each side
of the scanner cover when opening and closing it.
IMPORTANT
The telephone line cord MUST be connected to
the jack marked LINE on the machine.
NOTE
If you are sharing one telephone line with an
external telephone, connect it as shown below.
Before you connect the external telephone,
remove the white protective cap c from the EXT.
jack on the machine.
a Extension telephone
b External telephone
c Protective cap
NOTE
If you are sharing one telephone line with an
external telephone answering machine, connect it
as shown below.
Before you connect the external telephone
answering machine, remove the white protective
cap a from the EXT. jack on the machine.
a Protective cap
Set the receive mode to External TAD if you
have an external answering machine. See
Choose the correct Receive Mode on page 12.
For additional details, see Connecting an external
TAD (telephone answering device) in chapter 6 of
the Basic User’s Guide.
1
2
3
1

Other manuals for Brother MFC-J6925DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-J6925DW and is the answer not in the manual?

Brother MFC-J6925DW Specifications

General IconGeneral
Print technologyInkjet
Maximum resolution1200 x 6000 DPI
Economical printingYes
Duplex printing modeAuto
Print speed (ISO/IEC 24734) mono22 ipm
Print speed (ISO/IEC 24734) color20 ipm
Print speed (black, normal quality, A4/US Letter)35 ppm
Print speed (color, normal quality, A4/US Letter)27 ppm
Copier resize25 - 400 %
Maximum copy resolution1200 x 2400 DPI
Maximum number of copies99 copies
Scan toE-mail, E-mail Server, FTP, Memory Card, SMB, USB
Scan driversICA, TWAIN, WIA
Scanner typeFlatbed & ADF scanner
Grayscale levels256
Input color depth48 bit
Output color depth24 bit
Image formats supportedJPG, MJPEG, TIF
Maximum scan resolution19200 x 19200 DPI
Document formats supportedPDF
Optical scanning resolution2400 x 2400 DPI
FaxingColor faxing
Fax memory200 pages
Modem speed33.6 Kbit/s
Fax coding methodsMMR
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle- pages per month
Number of print cartridges4
Total input capacity500 sheets
Total output capacity50 sheets
Auto document feeder (ADF) input capacity35 sheets
Envelopes sizesC5, Com-10, DL, Monarch
Photo paper sizes9x13, 10x15, 13x18, 13x20 cm
Custom media width148 - 297 mm
Custom media length148 - 431.8 mm
Paper tray media typesCoated paper, Envelopes, Glossy paper, Photo paper, Plain paper, Transparencies
Non-ISO print media sizes2L, Executive (184 x 267mm), Folio (media size), Index card, L, Ledger (media size), Letter (media size)
ISO A-series sizes (A0...A9)A3, A4, A5, A6
Borderless printing media sizes2L, A3, A4, A6, Index card, L, Ledger, Letter
Maximum ISO A-series paper sizeA3
DisplayTFT
Control typeTouch
Product colorBlack, White
Display diagonal3.7 \
Market positioningBusiness
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms128-bit WEP, 64-bit WEP, APOP, SMTP-AUTH, SSID, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Online services supportedBox, Dropbox, Evernote, Facebook, Flickr, Google Drive, OneDrive, Picasa
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print
Standard interfacesEthernet, NFC, USB 1.1, USB 2.0, Wireless LAN
USB 1.1 ports quantity1
Fax compatibilityITU-T G3
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MiniSD, MiniSDHC, MMC, MMC Mobile, MMC+, MS Duo, MS Micro (M2), MS PRO Duo, SD, SDHC, SDXC
Sound pressure level (copying)50 dB
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.04 W
Power consumption (ready)5.5 W
Power consumption (average operating)29 W
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supportedAndroid, iOS, Windows Phone
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supportedWindows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Bundled softwareEmbedded Web Server \\r BRAdmin Light
Sustainability certificatesBlue Angel, ENERGY STAR
Storage temperature (T-T)20 - 33 °C
Operating temperature (T-T)10 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth433 mm
Width553 mm
Height310 mm
