Brother MFC-L6700DW Service Manual

1-7
Confidential
Model MFC-L6750DW MFC-L6800DW MFC-L6900DW MFC-L6902DW
Warm-up
time
From Sleep
mode
Less than 5.7 sec. at 73.4F / 50%RH (23°C / 50%RH) for the U.S.A./
Brazil
Less than 4.7 sec. at 73.4F / 50%RH (23°C / 50%RH) except for the
U.S.A./Brazil
From Power
OFF
 ON
Less than 27 sec. at 73.4F / 50%RH (23°C / 50%RH)
First print
time
From Ready
mode
Less than 7.5 secs at 73.4F (23°C)
From Sleep
mode
Less than 13.2 secs at 73.4F (23°C) for the U.S.A./Brazil
Less than 12.2 secs at 73.4F (23°C) except for the U.S.A./Brazil
Printing speed
(A4/Letter)
Up to 46/48 ppm
(Quiet Mode: Up to 25/26 ppm)
Up to 50/52 ppm
(Quiet Mode: Up to 25/26 ppm)
CPU Cortex-A9
800 MHz
Backup clock Up to 60 hours
Dimensions
(W x D x H)
Carton size 599 x 526 x 762 mm
(23.6 x 20.7
x 30.0 inch)
599 x 526 x 659 mm
(23.6 x 20.7 x
25.9 inch) except
for Italy-CONSIP
599 x 526 x 762 mm
(23.6 x 20.7
x 30.0 inch)
for Italy-CONSIP
599 x 526 x 762 mm
(23.6 x 20.7 x 30.0 inch) except for Oceania
599 x 526 x 659 mm
(23.6 x 20.7 x 25.9 inch) for Oceania
Machine
size
495 x 427 x 518 mm
(19.5 x 16.8 x 20.4 inch)
Weights
with carton 23.3 kg / 51.4 lb 22.6 kg / 49.8 lb
(for the U.S.A.)
22.9 kg / 50.4 lb
(for Europe except
Italy-CONSIP)
23.5 kg / 51.8 lb
(for Italy-CONSIP)
23.5 kg / 51.8 lb
(for the U.S.A.)
23.4 kg / 51.6 lb
(for Latin America)
23.8 kg / 52.4 lb
(for Europe)
22.5 kg / 49.7 lb
(for Oceania)
23.7 kg / 52.3 lb
(for Asia)
23.4 kg / 51.6 lb
without
carton,
with toner/
drum
18.8 kg / 41.4 lb 18.8 kg / 41.5 lb
(for the U.S.A.)
18.9 kg / 41.6 lb
(for Europe except
Italy-CONSIP)
19.0 kg / 41.9 lb
(for Italy-CONSIP)
19.0 kg / 41.9 lb
(for the U.S.A./
Latin America)
19.0 kg / 42.0 lb
(for Europe)
18.9 kg / 41.6 lb
(for Oceania)
19.1 kg / 42.2 lb
(for Asia)
19.0 kg / 41.9 lb
without
carton and
toner/drum
17.0 kg / 37.5 lb 17.2 kg / 37.9 lb
Specifications are subject to change without notice.

Brother MFC-L6700DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	48 ppm
Digital sender	-
Maximum duty cycle	100000 pages per month
Recommended duty cycle	0 - 5000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	48 cpm
Scan to	E-mail, FTP, File, Image, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Scan speed (black)	28 ppm
Scan speed (color)	20 ppm
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (black)	56 ppm
Duplex scan speed (color)	34 ppm
Document formats supported	DOCX, PDF, PPTX, XML, XPS
Email protocols	APOP, IMAP4, POP3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, APOP, EAP-FAST, SMTP-AUTH, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Online services supported	Dropbox, Evernote, Google Drive, OneDrive
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, POP3, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, LDAP, Web Services (Print/Scan), IMAP4
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	2.5 sec/page
Total input capacity	520 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	70 sheets
Envelopes sizes	6 3/4, 7 3/4, 9, 10
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
ISO A-series sizes (A0...A9)	A4, A5, A6
Duplex media weight (imperial)	17 - 24 lbs
Multi-purpose tray media types	Bond paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 32 lbs
Multi-Purpose Tray media weight (imperial)	16 - 53 lbs
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	4.85 \
Market positioning	Business
Internal memory	512 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	55 dB
Sustainability certificates	ENERGY STAR
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	36 W
Power consumption (sleep)	1.8 W
Power consumption (average operating)	680 W
Operating relative humidity (H-H)	20 - 80 %
Package depth	525.78 mm
Package width	599.44 mm
Package height	657.86 mm
Package weight	22089.95 g

Weight and Dimensions

Width	495.3 mm
