Page #359 background imageLoading...
Page #359 background image
5-44
Confidential
1.3.24 Configure for country/region and model (function code: 74)
<Function>
This function is used to customize the machine according to language, function settings, and
worker switch settings.
<Operating Procedure>
(1) Press the [7], and then the [4] key in the initial state of maintenance mode. The spec
code currently set is displayed on the LCD.
(2) Enter the spec code (four digits) you want to set.
(3)
Press the [Mono Start] key to save the new setting, and "PARAMETER INIT" is displayed
on the LCD. The machine then returns to the initial state of maintenance mode.
â–  Setting by spec code list
MODEL Spec Code Spec Code (Detail)
DCP-L5500D Iran 0035
--
DCP-L5500DN
CEE-General 1004
--
France/Belgium/
Netherlands
1058
Belgium 1008
France 7004
Netherlands 9004
Others 1004
Germany 1003
--
Italy/Iberia 1004
--
Pan-Nordic 1004
--
Russia 5004
--
Switzerland 3004
--
U.S.A 0001
--
UK 1004
--
DCP-L5502DN Brazil 0042
--
DCP-L5600DN
Argentina 0136
--
India 0145
--
Singapore 0140
--
U.S.A 0101
--
DCP-L5602DN Brazil 0142
--
DCP-L5650DN
Argentina 0236
--
Chile 0236
--
U.S.A 0201
--
DCP-L5652DN Brazil 0242
--
DCP-L6600DW
Generic 1367
Belgium 1308
France 7304
Netherlands 9304
Italy B304
Spain D304
Portugal F304
Others 1304
Germany 3304
--
Israel 1317
--
Pan-Nordic 1304
--
Russia 5304
--
Switzerland 3304
--
UK 1304
--
Note:
• If there is no entry for one minute or longer, the machine returns to the initial state of
maintenance mode automatically, regardless of the display status.
• The spec code list above is current as of March 2016.
• Please contact Brother distributors for the latest information.
