Brother MFC-L6700DW Service Manual

5-50
Confidential
1 Model name 33 Remaining life of PF kit 3
2 Serial number 34 Remaining life of PF kit 4
3 Model code 35 Total printed pages
4 Spec code 36 Total copied pages
5
Switch check sum (factory use)
and comparison of default / current value
37
Total PC printed pages
6 Main firmware version 38 Total fax pages
7 Sub firmware version 39 Total pages printed by other methods
8 Boot ROM version 40 Accumulated average coverage
9 Engine archive version 41
Average coverage by the current toner cartridge
10
ROM version for T2 control PCB
42
Average coverage by the previous
toner cartridge
11 ROM version for T3 control PCB 43 Latest job average coverage
12 TT firmware version 44 Drum page count
13 Memory version 45 Rotations of the drum
14
ROM check sum
46
Total rotations of the developer roller
(currently use/previously used toner cartridge)
15 RTC (Real Time Clock) check 47 Total printed pages per paper tray
16 RTC (Real Time Clock) backup 48 Total printed pages per paper type
17
RTC (Real Time Clock) time before
backup
49
Printed pages per (currently / previously
used) toner cartridge
18
RTC (Real Time Clock) time after
backup 50
Total number of rotations of the developer
roller per toner cartridge (currently /
previously used toner cartridge)
19 USB ID code 51 Pages printed per specified coverage range
20 RAM size 52 Paper jams by sections of the product
21
Function code: 05 result / Wireless LAN
setting by country / Wireless LAN output
peak / WLAN Setup YES/NO setting /
Current toner cartridge type / Previous
toner cartridge type / Main PCB
inspection log / High voltage inspection
log / The number of times that the
discharge error, fuser unit error, polygon
motor lock error, irregular power supply
detection error occurred / Next Power On
setting for Power Button
53
Machine error log /
Total pages printed at the time of the
error / Temperature and humidity
22
Process status
54
Number of times each consumable has
been replaced
23 Process status / Process checksum 55 Scanned pages
24
Not necessary for maintenance
(ADF sensor log)
56
Communication error log
25 Estimated remaining toner amount 57 Developing bias voltage value
26
Remaining life of drum unit
58
Engine sensor log
(Not necessary for maintenance)
27
Remaining life of fuser unit
59
Status log
(Not necessary for maintenance)
28
Remaining life of laser unit
60
Current temperature and humidity /
Highest and lowest temperature and
humidity in the past
29 Toner Low threshold setting 61 Total power distribution time
30
Remaining life of PF kit MP
62
The number of times that the power is
turned ON
31 Remaining life of PF kit 1 63 Start date for machine operation
32 Remaining life of PF kit 2 64 New toner cartridge detection log
