Brother MFC-L6700DW Service Manual

2-15
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
4C02 ― 5902 ―
4C03 ― 5A02 ―
4C04 ― 5B02 ―
4C05 ― 5C02 ―
4D01 ― 6001
The front cover sensor detected that
the front cover was open.
2-47
4E01 ― 6002 ―
4F01
The new toner sensor could not detect
the new toner cartridge correctly.
2-46
6003 ―
4F02 ― 6004
The eject sensor detected that the
fuser cover was open.
2-47
4F03 ― 6007 ―
4F04 ― 6101
The toner amount detection sensor
detected that the toner cartridge was
not set.
2-47
5001
Printable pages set for PF kit MP have
reached the upper limit.
2-46 6102 ―
5002
Printable pages set for PF kit 1 have
reached the upper limit.
2-46
6103 ―
5003
Printable pages set for PF kit 2 have
reached the upper limit.
2-46
6104 ―
5004
Printable pages set for PF kit 3 have
reached the upper limit.
2-46 6200
Detected that the drum unit was not set
by detecting the GRID terminal current.
2-48
5005
Printable pages set for PF kit 4 have
reached the upper limit.
2-46
6201 ―
5006
Printable pages set for PF kit 5 have
reached the upper limit.
2-46
6202 ―
5100 ― 6203 ―
5200 ― 6204 ―
5301 ― 6208 ―
5302 ― 6209 ―
5401 ― 620A ―
5402 ― 6300 ―
5406 ― 6400 ―
5502 ― 6602 ―
5602 ― 6701 ―
5702 ― 6801
The side thermistor of the fuser unit or
internal temperature sensor detected
a temperature higher than the
specified value.
2-49
5801 ― 6802 ―
5802 ― 6901
An error occurred in the fuser unit
when the power switch was turned
ON or sleep mode was released.
2-49

Brother MFC-L6700DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	48 ppm
Digital sender	-
Maximum duty cycle	100000 pages per month
Recommended duty cycle	0 - 5000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	48 cpm
Scan to	E-mail, FTP, File, Image, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Scan speed (black)	28 ppm
Scan speed (color)	20 ppm
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (black)	56 ppm
Duplex scan speed (color)	34 ppm
Document formats supported	DOCX, PDF, PPTX, XML, XPS
Email protocols	APOP, IMAP4, POP3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, APOP, EAP-FAST, SMTP-AUTH, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Online services supported	Dropbox, Evernote, Google Drive, OneDrive
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, POP3, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, LDAP, Web Services (Print/Scan), IMAP4
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	2.5 sec/page
Total input capacity	520 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	70 sheets
Envelopes sizes	6 3/4, 7 3/4, 9, 10
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
ISO A-series sizes (A0...A9)	A4, A5, A6
Duplex media weight (imperial)	17 - 24 lbs
Multi-purpose tray media types	Bond paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 32 lbs
Multi-Purpose Tray media weight (imperial)	16 - 53 lbs
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	4.85 \
Market positioning	Business
Internal memory	512 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	55 dB
Sustainability certificates	ENERGY STAR
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	36 W
Power consumption (sleep)	1.8 W
Power consumption (average operating)	680 W
Operating relative humidity (H-H)	20 - 80 %
Package depth	525.78 mm
Package width	599.44 mm
Package height	657.86 mm
Package weight	22089.95 g

Weight and Dimensions

Width	495.3 mm
