Brother MFC-L6700DW Service Manual

2-55
Confidential
 Error code 7402
When printing from the paper tray 2, the registration front sensor or the T2TT jam sensor
does not detect paper pass within the specified time after the T2(LT or TT) paper feed sensor
detected paper pass.
<User Check>
• Remove the jammed paper.
• Add the paper properly using the paper tray 2 paper guide.
• Install the latest main firmware.
Step Cause Remedy
1
Foreign object in the front of the
machine
Remove the foreign object.
2
Registration front actuator
attachment failure
Reattach the registration front actuator.
3
T2TT jam sensor attachment
failure
Reattach the T2TT jam sensor.
4
Connection failure of the
registration front/rear sensor
harness
Reconnect the registration front/rear sensor
harness.
5
Connection failure of the T2TT
jam sensor harness
Reconnect the T2TT jam sensor harness.
6
Connection failure of the TT
control PCB harness
Reconnect the TT control PCB harness.
7
Connection failure of the T2LT
control PCB harness
Reconnect the T2LT control PCB harness.
8
Connection failure of the T2LT
release clutch harness
Reconnect the T2LT release clutch harness.
9 T2LT release clutch failure Replace the T2LT release clutch.
10
Registration front/rear sensor
PCB failure
Replace the registration front/rear sensor PCB
ASSY.
11 T2TT jam sensor PCB failure Replace the T2TT jam sensor PCB ASSY.
12 TT control PCB failure Replace the TT control PCB ASSY.
13 T2LT control PCB failure Replace the T2LT control PCB ASSY.
14
high-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
15
Damaged gears in the paper
feeding system
Replace the main frame L ASSY.
16
Damaged gears in the LT paper
feeding system
Replace the LT.
17
Damaged gears in the TT paper
feeding system
Replace the TT.
18 Main PCB failure Replace the main PCB ASSY.
