7-16
Confidential
< Location of the laser serial number on the laser unit >
Fig. 7-19
Note:
• Attach the laser serial label to the position (on the laser plate) shown in the figure below
after replacing the laser unit.
Laser serial number label
Laser unit
Laser plate
Laser plate
