Brother PT-D600 Service Manual

III - 25
Press the key below, and the LCD displays as shown in <Figure 3.4-10> for LCD
check 5.
For European/North American models: [OK] or [ENTER]
Figure 3.4-10
Write head rank and settings by country data.
After writing, set the selected specification (language/unit).
After writing is completed, proceed to the "INFORMATION Mode".
* If the writing is failed, "NG" appears on the screen. Press the [OK] or [ENTER] key
to display as shown in <Figure 3.4-10>.
For European/North American models: [OK] or [ENTER]
The [ON / OFF] key is invalid while writing to the FROM.
3.5 INFORMATION Mode ([2] key):
Required on the Production Line
Be sure to provide power supply of DC12.0V ±0.1V / DC9.0V ±0.1V [Insert resistant
1Ω ±5% (2W and more)] for the inspection from DC power or AA battery.
Press the key below at the state of <Figure 3.4-10> to check the head rank, and the
LCD displays as shown in <Figure 3.5-1>.
For European/North American models: [OK], [ENTER] or [2]
Figure 3.5-1 Example of INFO Mode Indication
1:USA B
Country
Head rank

Brother PT-D600 Specifications

General

Model	PT-D600
Print Resolution	180 dpi
Max Tape Width	24 mm
Keyboard	QWERTY
Display	Color LCD
Power Source	AC Adapter or 6 AA Batteries
Connectivity	USB
Technology	Thermal Transfer
Tape Width	3.5mm, 6mm, 9mm, 12mm, 18mm, 24mm
Maximum Print Resolution	180 dpi
Maximum Print Speed	30 mm/sec
Cutter	Automatic
Memory	Up to 99 labels
Print Speed	30 mm/sec
Dimensions	201 mm x 192 mm x 86 mm
Weight	960 g (without tape and batteries)
