Brother RH-9800 User Manual (English)

Other manuals for Brother RH-9800

Questions and Answers:

J
Jose GallowayJul 29, 2025
What to do if my Brother Sewing Machine is skipping stitches?
- I
  Ian SmithJul 29, 2025
  If the thread tension control nut pressure is too strong or too weak, adjust it to an appropriate pressure. If the needle point is broken or bent, replace it with a new one. If the needle and looper adjustment or clearance is incorrect, adjust correctly. Also, ensure the needle and needle guard adjustment is correct. A blunt looper tip can also cause skipped stitches; repair it with an oilstone or replace it.
M
Melissa SkinnerAug 2, 2025
Why does the thread keep breaking on my Brother RH-9800?
- J
  John SantiagoAug 3, 2025
  If the thread tension control nut pressure is too strong, adjust it to an appropriate pressure. If the thread is of poor quality, use a better-quality thread. If the thread is too thick for the needle, use a different-size needle. If the needle groove or needle hole are not smooth, replace the needle. If the needle and looper adjustment is incorrect, adjust the needle bar height or the looper and spreader height. Damaged components like the needle, looper, or thread path should be repaired or replaced.
L
Linda PayneAug 6, 2025
What causes the needle to break on my Brother RH-9800?
- V
  Victor WhiteAug 7, 2025
  If the needle is bent, replace it. If the needle and looper adjustment is incorrect, adjust the needle bar height or the looper and spreader height. If the needle and needle guard adjustment is incorrect, adjust correctly.
B
Brooke SimonAug 11, 2025
How to fix a Brother RH-9800 when the lower thread is not cut?
- M
  Michael RandallAug 11, 2025
  If the knife is blunt, replace it with a new one. If the knife does not move to the full stroke because air pressure is too weak, adjust the air pressure. If the movable knife position is incorrect, adjust the position of the movable knife or the loop spreader.
B
brownjuliaAug 15, 2025
Why is the upper thread not being cut on my Brother RH-9800 Sewing Machine?
- C
  Cassandra LunaAug 15, 2025
  If the knife is blunt, replace it. If the knife doesn't move fully due to weak air pressure, adjust the pressure. If the upper thread trimmer knife isn't picking up the upper thread, install it so it cuts only one side of the upper thread loop. If the movable knife isn't picking up the needle thread because the last stitch is skipped, refer to the remedies given under “Skipped stitches occur”. If the movable knife position is incorrect, adjust its position or the loop spreader.
F
Frank ChambersAug 19, 2025
What to do if the thread slips out of the needle at the sewing start on my Brother RH-9800?
- S
  Sergio BartlettSep 12, 2025
  If the thread nipper spring force is too weak, adjust the force of the thread nipper spring. If the upper thread length is too short after trimming, install the upper thread trimmer knife so that it cuts only one side of the upper thread loop. If the needle and looper adjustment is incorrect, adjust the needle bar height or the looper and spreader height. If not enough upper thread is being fed out, adjust the amount of upper thread being fed out.
C
Christopher CampbellAug 25, 2025
How to resolve material not being cut cleanly with my Brother RH-9800 Sewing Machine?
- M
  marcuschristianAug 25, 2025
  If the cutting pressure is too weak, adjust the cutting pressure so that it is strong enough. If the knife and cutting block are not contacting properly, grind the cutting block surface. If the knife is blunt, replace it with a new knife. If the cutter arm operation time is too short, make the operation time longer by changing the memory switch setting.

Brother RH-9800 Specifications

General

Maximum stitch length	5mm
Maximum stitch width	7mm
Free arm	Yes
Apparel sewing machine	Yes
Application	Household
LCD screen	Yes
Included feet	Buttonhole foot, Overcasting foot, Zipper foot, Blindstitch foot, Button fitting foot, Monogramming foot, Embroidery foot
Bobbin	Top drop-in
Speed control	Variable
Needle positions	Variable needle positions
Presser foot pressure	Adjustable
Warranty	25 year limited warranty
