3 of 24
REMOTE CONTROL FEATURES
List of Features
• Neutral Lock
• “Start in gear prevention” switch
• Warning horn included
• Adjustable throttle friction
• Pigtail wiring harness – correct ignition wir-
ing harness must be ordered separately
• Uses standard Evinrude / Johnson control
cables (1979 and newer type)
9
7
6
1
7
1
2
3
4
5
8
3
6
1. Trim and tilt switch
2. Remote control lever
3. Fast idle lever
4. Emergency stop / key switch
5. Clip and lanyard assembly
6. Adjusting screw, remote control lever friction
7. Neutral lock lever
8. Shift position label
9. Handle, shift and throttle
004849
Nautical Orientation
004861
