5
Tachometer
The tachometer(s) provide an analog indication of the revolutions per min-
ute (RPM) of the engine(s).
Speedometer
The speedometer provides an indication of speed in miles per hour (MPH)
or kilometers per hour (km/h).
On a single engine information center it is located on the left side of the ana-
log gauge cluster. On a dual engine information center it is located in the dig-
ital display.
Indicator Lights
Indicator lights are located in the speedometer and tachometers and display
a selected function, a normal condition, or a system anomaly.
An indicator light may be accompanied by a scrolling message in the multi-
function display. See table below for usual indicator light information.
Continued on next page.
Indicator
Light
Display Area
Message Display Description
Single
Engine
Information
Center
Dual
Engine
Information
Center
Speedometer
Left Side
Tachometer
SKI MODE related mes-
sages
When ON: SKI MODE is
engaged.
When blinking: SKI MODE is
selected but not engaged.
Speedometer
Left Side
Tachometer
CRUISE MODE related
messages
CRUISE mode engaged.
Speedometer
Left Side
Tachometer
Engine or exhaust system overheating (H-TEMP).
Audible alarm will sound and limp-home mode will activate.
Speedometer
Left Side
Tachometer
Low/High battery voltage (12 V LOW/HI)
Speedometer
Left Side
Tachometer
Maintenance required or
Service Vehicle Soon
(Fault)
Could be turned on by the mainte-
nance counter or by a non-emis-
sion related fault that is active or
has been in the system and not
completed three healing drive
cycles.
