MAINTENANCE MANUAL LINE
NOTE
If there is slight vertical run-out, replace the nut and repeat the measurement.
Step
Procedure
5
Insert 2 6x20 dowel pins into the crankcase.
6
Apply Engine oil into the needle bearing and lubricate the crankshaft
with LOCTITE Anti Seize.
Figure 5.11
1
Dowel pins 6x20
NOTICE
If excessive installation force is used, the bearing or vacuum pump gear can be
damaged.
Step
Procedure
7
Check the overload clutch for correctly installation. Observe the mark.
05–50–00
Page 14
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
