Bruker CTX - Page 12

S1 TITAN, T
RACER
5, and CTX User Manual
030.0
112.04.0
12 of 67
Chan
ging
filters
To cha
nge manual filters attached to a collimator
–
Step
Act
ion
1
Note
the configuration of the
curren
t
filter
holder on the collimator.
2
Using the provided 0.050 inch hex
screwdri
ver, unscrew the filter holder from
the collimator.
3
Alig
n the new filter holder with the collimator.
Note
the metal band fits into the collimator.
4
Attach the scr
ew
.
