Copyright 5/09 PAGE 69
MODELS 2000XP / 2100SP
+ -
BLK GROUND 3
RED AUTOFEED INPUT 4
7 RED/WHT/YEL OUTPUT ENABLE
RED/WHT/YEL POWER 6
12 BLK GROUND 6 RED AUTOFEED ENGAGE 9 TAN TONGUE IN 4 TAN/BLK TONGUE OUT
2 ORG/BLK SWING LEFT 5 BLU/BLK LIFT DOWN 8 BLU LIFT UP 11 ORG SWING RIGHT
ORG/BLK SWING LEFT 11
BLU/BLK LIFT DOWN 2
BLU LIFT UP 3
ORG SWING RIGHT 12
3 GRN DRIVE HIGH 8 YEL/BLK STEER LEFT 9 GRY E-STOP
GRY E-STOP 5
YEL/BLK STEER LEFT 1
GRN DRIVE HIGH 9
TAN TONGUE IN 10
TAN/BLK TONGUE OUT 11
2 PNK DRIVE FORWARD 5 YEL STEER RIGHT 11 PNK/BLK DRIVE REVERSE
PNK/BLK DRIVE REVERSE 9
YEL STEER RIGHT 10
PNK DRIVE FORWARD 6
RED/WHT/YEL POWER TO RADIO RED POWER FROM MACHINE HARNESS RED POWER TO LOCAL SWITCHES
GRY
BLK
SPECIFIC SCHEMATIC FUNCTION MAY VARY DEPENDING
ON OPTIONS OR COMPONENT MANUFACTURER.
ELECTRICAL SCHEMATIC (993-8000-11)
LOR TO OMNEX RADIO HARNESS
ELECTRICAL SECTION
