Bryant 359AAV - Page 7

7
Plastic Cap
Yellow or black
Vent Drain
&Clamps
INLET
EXHAUST
IN
ON
OFF
V
E
N
T
Casing Grommet
Black Rubber
5
/
8
″
(15.9mm) ID
(Loose parts bag)
Drain Connector Black PVC
3
/
4
″
(19.1mm) PVC X
1
/
2
″
(12.7mm) CPVC
(Loose parts bag)
Drain Tube
Corrugated
5
/
8
″
(15.9mm) ID
&Clamps
Coupling & Clamps
(Optional)
25--24--67a
Single Pressure Switch
Dual Pressure Switch Detail
Tee Trap White PVC
(loose parts bag)
2
″
(50.8mm) PVC
Coupling
On Some Models
ONLY
Rotate downward
5
°
to 10
°
NOTE: Built--in channel will
be angled 5° to 10° also.
SIDE VIEW
Either: The PVC
Drain Tee or a field
supplied 2
″
(50.8mm) PVC Tee
AIR
FLOW
AIR
FLOW
Relief Tube
Black Rubber
3
/
16
″
(4.8mm) ID
Drain Tube
Black Rubber
1
/
2
″
(12.7mm) ID
&Clamps
Representative drawing only, some models may vary in appearance.
Drain Line Vent Tee
3
/
4
″
(18.1mm) PVC or
1
/
2
″
(12.7mm) CPVC (Field supplied)
A07707
Fig. 7 -- Upflow Installations Vent Through Left Side
359AAV
