Bryant 359AAV - Page 8

8
EXHAUST
AIR FLOW
INLET
IN
ON
OFF
V
E
N
T
Casing Grommet
Black Rubber
5
/
8
″
(15.9mm) CPVC
(Loose parts bag)
Drain Connector Black PVC
3
/
4
″
(19.1mm) PVC X
1
/
2
″
(12.7mm) CPVC
(Loose parts bag)
25--24--68
Single Pressure Switch Details
Dual Pressure Switch
Tee Trap White PVC
(loose parts bag)
2
″
(50.8mm)
PVC
Coupling
Barbed Coupling,
1
/
2
″
(12.7mm) OD
(loose parts bag)
Rotate
downward
5
°
to 10
°
NOTE: Built--in channel will
be angled 5° to 10° also.
SIDE VIEW
Plastic Cap
Yellow or black
Vent Drain
&Clamps
On Some Models
ONLY
Either: The PVC Drain
Tee or a field supplied
2
″
(50.8mm) PVC Tee
Relief Tube
Black Rubber
3
/
16
″ 〈
4.8mm) ID
Elbow Tubes (2) Black Rubber
1
/
2
″
(12.7mm) ID & Clamps
(loose parts bag)
Drain Tube
Corrugated
5
/
8
″
(15.9mm) ID &
Clamps
Drain Line Vent Tee
3
/
4
″
(18.1mm) PVC or
1
/
2
″
(12.7mm) CPVC (Field sup-
plied)
A07708
Fig. 8 -- All Models Vent Through Right Side (Upflow)
359AAV
