PERFORMANCE DATA 577C----A24
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES °F(°C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM/BF
EWB
°F(°C)
Capacity MBtuh
To t a l
Sys
kW
Capacity MBtuh
To t a l
Sys
kW
Capacity MBtuh
To t a l
Sys
kW
Capacity MBtuh
To t a l
Sys
kW
Capacity MBtuh
To t a l
Sys
kW
Capacity MBtuh
To t a l
Sys
kW
To t a l Sens To t a l Sens To t a l Sens To t a l Sens To t a l Sens To t a l Sens
VL-A24 Outdoor Section With NONE Indoor Sect ion
700/0.02
57
(13.8)
22.98 22.98 1.47 21.68 21.68 1.68 20.31 20.31 1.90 18.78 18.78 2.14 17.08 17.08 2.40 15.36 15.36 2.68
62
(16.6)
23.82 21.37 1.48 22.23 20.56 1.68 20.58 19.70 1.91 18.81 18.81 2.14 17.11 17.11 2.40 15.39 15.39 2.68
63*
(17.2)
24.35 17.47 1.49 22.73 16.72 1.69 21.04 15.94 1.91 19.13 15.07 2.15 16.92 14.08 2.39 14.70 13.09 2.66
67
(19.4)
26.42 18.21 1.49 24.76 17.49 1.71 23.03 16.75 1.95 21.14 15.93 2.20 18.89 14.98 2.44 16.58 14.01 2.71
72
(22.2)
28.85 14.79 1.50 27.32 14.23 1.72 25.63 13.61 1.96 23.80 12.93 2.23 21.65 12.14 2.52 19.22 11.24 2.79
800/0.03
57
(13.8)
24.12 24.12 1.50 22.76 22.76 1.71 21.34 21.34 1.94 19.80 19.80 2.18 17.99 17.99 2.43 16.19 16.19 2.72
62
(16.6)
24.50 23.07 1.50 22.90 22.19 1.71 21.38 21.38 1.94 19.84 19.84 2.18 18.02 18.02 2.44 16.22 16.22 2.72
63*
(17.2)
25.00 18.69 1.50 23.32 17.92 1.72 21.58 17.12 1.94 19.66 16.24 2.18 17.37 15.21 2.42 15.09 14.18 2.69
67
(19.4)
27.05 19.46 1.51 25.38 18.76 1.72 23.60 18.00 1.97 21.66 17.17 2.23 19.36 16.20 2.47 17.00 15.20 2.74
72
(22.2)
29.34 15.47 1.53 27.83 14.96 1.74 26.14 14.36 1.98 24.31 13.70 2.25 22.19 12.94 2.54 19.67 12.02 2.83
900/0.04
57
(13.8)
25.11 25.11 1.52 23.69 23.69 1.74 22.22 22.22 1.97 20.65 20.65 2.22 18.78 18.78 2.47 16.90 16.90 2.76
62
(16.6)
25.16 25.16 1.52 23.73 23.73 1.74 22.26 22.26 1.97 20.68 20.68 2.22 18.81 18.81 2.47 16.93 16.93 2.76
63*
(17.2)
25.49 19.84 1.52 23.79 19.07 1.74 22.01 18.25 1.97 20.08 17.36 2.21 17.74 16.30 2.45 15.43 15.18 2.72
67
(19.4)
27.52 20.63 1.53 25.83 19.96 1.74 24.04 19.20 1.98 22.07 18.37 2.25 19.75 17.37 2.50 17.35 16.33 2.77
72
(22.2)
29.68 16.09 1.55 28.19 15.62 1.76 26.50 15.05 2.00 24.67 14.41 2.27 22.61 13.70 2.57 20.03 12.76 2.86
