Bryant 577C--A - Performance Data; Cooling Capacities and Efficiencies

14
PERFORMANCE DATA 577C----A30
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES °F(°C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM/BF
EWB
°F(°C)
Capacity MBtuh
To t a l
Sys
kW
Capacity MBtuh
To t a l
Sys
kW
Capacity MBtuh
To t a l
Sys
kW
Capacity MBtuh
To t a l
Sys
kW
Capacity MBtuh
To t a l
Sys
kW
Capacity MBtuh
To t a l
Sys
kW
To t a l Sens To t a l Sens To t a l Sens To t a l Sens To t a l Sens To t a l Sens
VL-A30 Outdoor Section With NONE Indoor Sect ion
875/0.03
57
(13.8)
26.99 26.99 1.86 26.03 26.03 2.08 24.84 24.84 2.31 23.28 23.28 2.55 21.63 21.63 2.82 19.83 19.83 3.11
62
(16.6)
27.80 26.01 1.87 26.54 25.26 2.08 25.04 24.35 2.31 23.33 23.33 2.55 21.67 21.67 2.82 19.87 19.87 3.11
63*
(17.2)
28.37 21.21 1.87 27.09 20.50 2.09 25.54 19.70 2.32 23.41 18.68 2.55 21.13 17.63 2.81 18.66 16.51 3.08
67
(19.4)
30.73 22.07 1.86 29.48 21.44 2.10 27.98 20.72 2.35 25.91 19.78 2.59 23.61 18.78 2.85 21.10 17.72 3.13
72
(22.2)
33.46 17.78 1.87 32.40 17.30 2.10 31.09 16.72 2.36 29.42 16.04 2.64 27.07 15.10 2.93 24.52 14.14 3.21
1000/0.04
57
(13.8)
28.26 28.26 1.89 27.27 27.27 2.12 26.09 26.09 2.36 24.45 24.45 2.59 22.72 22.72 2.87 20.84 20.84 3.16
62
(16.6)
28.57 27.98 1.89 27.32 27.32 2.13 26.13 26.13 2.36 24.49 24.49 2.60 22.76 22.76 2.87 20.87 20.87 3.16
63*
(17.2)
29.05 22.65 1.89 27.73 21.95 2.13 26.16 21.15 2.36 23.97 20.11 2.59 21.65 19.03 2.85 19.13 17.84 3.12
67
(19.4)
31.37 23.54 1.89 30.12 22.95 2.12 28.60 22.25 2.38 26.53 21.33 2.63 24.15 20.29 2.89 21.60 19.20 3.18
72
(22.2)
33.95 18.56 1.90 32.92 18.14 2.14 31.61 17.60 2.39 30.05 16.99 2.68 27.65 16.09 2.98 25.04 15.12 3.26
1125/0.05
57
(13.8)
29.32 29.32 1.92 28.31 28.31 2.15 27.10 27.10 2.41 25.45 25.45 2.64 23.65 23.65 2.91 21.70 21.70 3.21
62
(16.6)
29.36 29.36 1.92 28.35 28.35 2.15 27.14 27.14 2.41 25.49 25.49 2.64 23.68 23.68 2.92 21.73 21.73 3.21
63*
(17.2)
29.55 24.01 1.92 28.22 23.33 2.15 26.63 22.53 2.40 24.43 21.47 2.62 22.07 20.33 2.88 19.66 19.66 3.17
67
(19.4)
31.84 24.91 1.92 30.59 24.37 2.15 29.08 23.70 2.41 27.00 22.80 2.68 24.60 21.73 2.93 22.02 20.55 3.22
72
(22.2)
34.29 19.27 1.94 33.28 18.91 2.17 31.97 18.40 2.43 30.44 17.85 2.71 28.11 17.06 3.01 25.43 16.05 3.31
See Legend and Notes on Page 19.
577C-- --A
