Bryant 604B - PERFORMANCE DATA - HEATING 30-60; HEATING EXTENDED PERFORMANCE TABLE 30-60

—13—
PERFORMANCE DATA (CONT)–STANDARD ECM INDOOR MOTOR
COOLING EXTENDED PERFORMANCE TABLE
HEATING EXTENDED PERFORMANCE TABLE -10–20
HEATING EXTENDED PERFORMANCE TABLE 30–60
*At 75°F entering dry bulb—Tennessee Valley Authority [TVA] rating conditions; all others at 80°F entering dry bulb.
See Legend and Notes on page 17.
604B036 COOLING PERFORMANCE TABLE
Temp (F)
Outdoor Air
Entering
Condenser
Evaporator Air—CFM/BF
1100/0.06 1225/0.07 1400/0.08
Evaporator Air — Ewb (F)
62 63* 67 72 62 63* 67 72 62 63* 67 72
75
TC 36.2 36.8 39.7 43.8 36.9 37.4 40.3 44.4 37.9 38.1 41.0 45.1
SHC 33.2 26.7 27.8 22.3 34.7 27.9 29.0 23.1 36.9 29.6 30.9 24.2
kW 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.8 2.8 2.8 2.8 2.9
85
TC 34.6 35.1 37.9 41.8 35.3 35.6 38.4 42.4 36.4 36.3 39.1 43.1
SHC 32.4 26.0 27.1 21.6 34.0 27.1 28.3 22.4 35.6 28.9 30.2 23.6
kW 2.9 2.9 3.0 3.0 3.0 3.0 3.0 3.0 3.1 3.1 3.1 3.2
95
TC 33.0 33.4 36.0 39.7 33.7 33.8 36.5 40.2 34.8 34.4 37.0 40.8
SHC 31.6 25.3 26.4 20.9 32.9 26.4 27.6 21.7 34.4 28.1 29.4 22.8
kW 3.2 3.2 3.3 3.3 3.3 3.3 3.3 3.4 3.4 3.4 3.4 3.5
105
TC 31.3 31.5 34.0 37.5 32.1 31.9 34.3 37.9 33.1 32.4 34.9 38.4
SHC 30.6 24.5 25.6 20.1 31.5 25.7 26.8 20.9 32.8 27.3 28.6 22.0
kW 3.6 3.6 3.6 3.6 3.6 3.6 3.7 3.7 3.8 3.7 3.8 3.8
115
TC 29.6 29.4 31.8 35.0 30.4 29.8 32.1 35.4 31.3 30.3 32.6 35.8
SHC 29.3 23.7 24.8 19.3 30.0 24.8 26.0 20.0 31.0 26.4 27.7 21.1
kW 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.1 4.1 4.1 4.2
125
TC 27.8 27.2 29.4 32.4 28.4 27.5 29.7 32.7 29.3 28.0 30.1 33.0
SHC 27.5 22.8 23.9 18.4 28.2 23.8 25.0 19.1 29.0 25.4 26.7 20.2
kW 4.4 4.3 4.4 4.4 4.4 4.4 4.4 4.4 4.5 4.5 4.5 4.5
604B036
Return
Air (F db)
CFM (Standard Air)
Air Temperature Entering Outdoor Coil (F db at 70% rh)
-10 0 10 1720
60
1100
TC 12.1
11.2 15.1 13.9 18.5 16.9 21.4 19.5 22.8 20.7
kW 2.25 2.34 2.43 2.49 2.51
1225
TC 12.3
11.4 15.4 14.2 18.7 17.2 21.7 19.7 22.9 20.7
kW 2.28 2.37 2.44 2.50 2.53
1400
TC 12.8
11.8 15.8 14.6 19.3 17.7 22.0 20.1 23.2 21.0
kW 2.37 2.44 2.53 2.56 2.59
70
1100
TC 11.1
10.3 14.3 13.1 17.6 16.1 20.6 18.8 21.9 19.9
kW 2.43 2.55 2.65 2.74 2.77
1225
TC 11.4
10.5 14.5 13.4 17.9 16.4 20.6 18.8 22.4 20.3
kW 2.47 2.58 2.67 2.76 2.78
1400
TC 11.8
10.9 15.0 13.8 18.4 16.9 21.2 19.3 23.0 20.8
kW 2.51 2.65 2.73 2.82 2.82
80
1100
TC 10.0
9.2 13.2 12.2 16.7 15.3 19.3 17.6 20.8 18.8
kW 2.61 2.75 2.89 2.97 3.01
1225
TC 10.2
9.5 13.5 12.5 17.0 15.6 19.6 17.9 21.2 19.2
kW 2.65 2.79 2.91 2.99 3.03
1400
TC 10.7
9.9 14.1 13.0 17.5 16.1 20.1 18.4 21.7 19.7
kW 2.73 2.87 2.97 3.05 3.08
604B036
Return
Air (F db)
CFM (Standard Air)
Air Temperature Entering Outdoor Coil (F db at 70% rh)
30 40 47 50 60
60
1100
TC 27.3
23.9 32.6 32.6 36.6 36.6 37.8 37.8 42.1 42.1
kW 2.59 2.68 2.74 2.77 2.86
1225
TC 27.6
24.2 32.8 32.8 36.8 36.8 37.9 37.9 42.2 42.2
kW 2.60 2.67 2.72 2.75 2.83
1400
TC 28.0
24.5 33.0 33.0 37.0 37.0 38.2 38.2 42.2 42.2
kW 2.65 2.71 2.75 2.77 2.84
70
1100
TC 26.9
23.6 32.1 32.1 36.0 36.0 37.1 37.1 41.2 41.2
kW 2.84 2.94 3.01 3.04 3.14
1225
TC 27.1
23.7 32.3 32.3 36.2 36.2 37.3 37.3 41.4 41.4
kW 2.85 2.94 3.00 3.03 3.12
1400
TC 27.5
24.1 32.5 32.5 36.4 36.4 37.5 37.5 41.6 41.6
kW 2.90 2.97 3.02 3.04 3.11
80
1100
TC 26.7
23.4 31.6 31.6 35.5 35.5 36.5 36.5 40.4 40.4
kW 3.13 3.23 3.30 3.33 3.44
1225
TC 26.9
23.5 31.8 31.8 35.6 35.6 36.7 36.7 40.6 40.6
kW 3.13 3.23 3.29 3.32 3.42
1400
TC 27.2
23.9 32.3 32.3 35.9 35.9 37.0 37.0 40.8 40.8
kW 3.17 3.25 3.30 3.33 3.40
