Bryant 830SA - Page 3

3
NOTE: ALL DIMENSIONS IN INCH (MM) U.S. ECCN: Not Subject to Regulation (N.S.R.)
SD5507--- 4 ULN 80 REV. B
A190257
Fig. 1 -- Dimensional Drawing
Table1–Dimensions
FURNACE SIZE
A
CABINET
WIDTH
IN. (MM)
B
OUTLET
WIDTH
IN. (MM)
C
TOP FLUE
COLLAR ONLY
IN. (MM)
D
BOTTOM
INLET WIDTH
IN. (MM)
VENT
CONNEC-
TION
IN. (MM)
SIZE
SHIP
WT. LB.
(KG)
A
CCESSORY
FILTER
MEDIA
CABINET
SIZE
IN. (MM)
36040E17
1 7 --- 1
/
2 (445) 1 5 --- 7
/
8 (403) 1 1 --- 9
/
16 (294) 16 (406) 4 (102) 118 (54) 16 (406)
48060E17
1 7 --- 1
/
2 (445) 1 5 --- 7
/
8 (403) 1 1 --- 9
/
16 (294) 16 (406) 4 (102) 126 (57) 16 (406)
60080E21
21 (533) 1 9 --- 3
/
8 (492) 1 3 --- 5
/
16 (338) 1 9 --- 1
/
2 (495) 4 (102) 140 (64) 20 (508)
60100E21
21 (533) 1 9 --- 3
/
8 (492) 1 3 --- 5
/
16 (338) 1 9 --- 1
/
2 (495) 4 (102) 150 (68) 20 (508)
