FURNACE SIZE
A B C D
SHIP WT.
LB (KG)
CABINET WIDTH OUTLET WIDTH BOTTOM INLET WIDTH AIR INTAKE
30040
14--- 3/ 16 (361) 12--- 1/ 2 (319) 12--- 9/ 16 (322) 7--- 1/ 8 (181)
112.0 (50.8)
36060 122.5 (55.6)
36040
17--- 1/ 2 (445) 15--- 7/ 8 (403) 16 (406) 8--- 3/ 4 (222)
122.0 (55.3)
42060 132.0 (59.9)
48080 142.0 (64.4)
60080
21 (533) 19--- 3/ 8 (492) 19--- 1/ 2 (495) 10--- 1/2 (267)
150.0 (68.0)
60100 160.0 (72.6)
60120 24--- 1/ 2 (622) 22--- 7/ 8 (581) 23 (584) 12--- 1/ 4 (311) 183.0 (83.0)
Fig. 1 -- Dimensional Drawing
