2
SAP ORDERING
NO.
CASING
DIMENSIONS
(IN.)
RATED HEATING†
OUTPUT (BTUH)
HEATING
AIRFLOW
COOLING
CFM
@0.5ESP
MOTOR
HP-SPEED
MEDIA
CABINET
SUPPLIED
(IN.)
APPROX.
SHIP WT
(LB)
H D W BTUH AFUE
ENERGY
STAR
Heating
CFM
‡
Heating
ESP
925SA30040E14 35 30 14.2 39,000 96.2% √ 695 0.10 385-925 1/2 - 5 16 120
925SA42060E17 35 30 17.5 58,000 96.2% √ 1000 0.12 530-1505 3/4 - 5 16 141
925SA48060E17 35 30 17.5 78,000 96.2% √ 1360 0.15 920-1610 3/4 - 5 16 151
925SA60080E21 35 30 21.0 78,000 96.2% √ 1360 0.15 795-2015 1-5 20 156
925SA60100E21 35 30 21.0 97,000 96.2% - 1700 0.20 1105-2110 1-5 20 166
925SA66120E24 35 30 24.5 117,000 96.2% - 2125 0.20 1385-2055 1-5 24 190
† Capacity in accordance with DOE test procedures. See rating plate.
‡ Heating CFM at factory default blower motor heating tap settings.
ESP --- External Static Pressu re
√ Meets ENERGY STAR criteria
FEATURES AND BENEFITS
SmartEvapt Technology — When paired with a compatible
thermostat, this dehumidification feature overrides the cooling
blower off-delay when there is a call for dehumidification. By
deactivating the blower off-delay, SmartEvap technology prevents
condensate that remains on the coil after a dehumidification cycle
from re-humidifying throughout the home. This results in reduced
humidity and a more comfortable indoor environment for the
homeowner.
Unlike competitive systems, SmartEvap technology only overrides
the cooling blower off delay. when humidity control is needed.
Once humidity is back in control, SmartEvap re-enables the
energy-saving cooling blower off-delay.
FanOnPlust Technology — Sometimes the constant fan setting
on a standard furnace system can actually reduce homeowner
comfort by providing too much or too little air! Fan On Plus
technology improves comfort all year long by allowing the
homeowner to select the continuous fan speed of their choice using
a compatible thermostat.
HYBRID HEATR Dual Fuel system — This system can provide
more control over your monthly energy bills by automatically
selecting the most economical method of heating. With HYBRID
HEAT, our system automatically switches between the gas furnace
and the electric heat pump as outside temperatures change to
maintain greater efficiency and comfort than with any traditional
single-source heating system. The heat pump also delivers
high-efficiency cooling in the summer.
Power Heatt Igniter — Bryant’s unique SiN igniter is not only
physically robust but it is also electrically robust. It is capable of
running at line voltage and does not require complex voltage
regulators as do other brands. This unique feature further enhances
the gas furnace reliability and continues Bryant’s tradition of
technology leadership and innovation in providing a reliable and
durable product.
Boost ECM Blower Motor — This basic ECM, or electronically
commutated motor, can provide an efficiency enhancement for
select Bryant air conditioner or heat pump systems. It uses less
electrical power than its PSC counterpart and also has a wider
range of speeds
Reliable Heat Exchanger Design — The aluminized steel,
clamshell primary heat exchanger was reengineered to achieve
greater efficiency out of a smaller size. The first two passes of the
heat exchanger are based on the current 80% product, a design
with more than ten years of field-proven performance and success.
These innovations, paired with the continuation of a crimped,
no-weld seam create an efficient, robust design for this essential
component.
The condensing heat exchanger, a stainless steel fin and tube
design, is positioned in the furnace to extract additional heat.
Stainless steel coupling box componentry between heat exchangers
has exceptional corrosion resistance in both natural gas and
propane applications.
Media Filter Cabinet — Enhanced indoor air quality in the home
is made easier with our media filter cabinet—a standard accessory
on all deluxe furnaces. When installed as a part of the system, this
cabinet allows for easy and convenient addition of a Bryant high
efficiency air filter.
4-Way Multipoise Design — One model for all applications –
there is no need to stock special downflow or horizontal models
when one unit will do it all. The new heat exchanger design allows
these units to achieve the certified AFUE in all positions.
Direct or Single-pipe Venting, or Optional Ventilated
Combustion Air — This furnace can be installed as a 2-pipe
(Direct Vent) furnace, in an optional ventilated combustion air
application, or in single-pipe, non-direct vent applications. This
provides added flexibility to meet diverse installation needs.
Sealed Combustion System — This furnace brings in combustion
air from outside the furnace, which results in especially quiet
operation. By sealing the entire combustion vestibule, the entire
furnace can be made quieter, not just the burners.
Insulated Casing — Foil-faced insulation in heat exchanger
section of the casing minimizes heat loss. The acoustical insulation
in the blower compartment reduces air and motor noise for quiet
operation.
Monoport Burners — The burners are specially designed and
finely tuned for smooth, quiet combustion and economical
operation.
Bottom Closure — Factory--installed for side return; easily
removable for bottom return. The multi-use bottom closure can
also serve for roll-out protection in horizontal applications, and act
as the bottom closure for the optional return air base accessory.
Blower Access Panel Switch
— Automatically shuts off 115-v
power to furnace whenever blower access panel is opened.
Quality Registration — Our furnaces are engineered and
manufactured under an ISO 9001 registered quality system.
Certifications — This furnace is CSA (AGA and CGA) design
certified for use with natural and propane gases. The furnace is
factory--shipped for use with natural gas. A CSA listed gas
conversion kit is required to convert furnace for use with propane
gas. The efficiency is GAMA efficiency rating certified. This
furnace meets California Air Quality Management District
emission requirements.
925SA
