SPECIFICATIONS
Heating Capacity and Efficiency 30040 42060 48080 60080 60100 66120
Input
High
Heat
(BTUH) 40,000 60,000 80,000 80,000 100,000 120,000
Output
High
Heat
(BTUH) 39,000 58,000 78,000 78,000 97,000 117,000
Efficiency AFUE % (ICS) 96.2 96.2 96.2 96.2 96.2 96.2
Certified Temperature
Rise Range ºF (ºC)
High Heat
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
Airflow Capacity and Blower Data 30040 42060 48080 60080 60100 66120
Certified External Static
Pressure (in. w.c.)
Heating 0.10 0.12 0.15 0.15 0.20 0.20
Cooling 0.5 0.5 0.5 0.5 0.5 0.5
Airflow Delivery
@ Rated ESP (CFM)
High Heat 695 1000 1360 1360 1700 2125
Cooling 925 1505 1610 2015 2110 2055
Cooling Capacity (tons)
@ 400, 350 CFM/ton
400 CFM/
ton
2 3.5 4 5 5 5
350 CFM/
ton
2.5 4 4.5 5.5 6 6
Direct-Drive Motor Type Electronically Commutated Motor (ECM)
Direct-Drive Motor HP 1/2 3/4 3/4 1 1 1
Motor Full Load Amps 6.8 8.4 8.4 10.9 10.9 10.9
RPM Range 600 - 1200
Speed Selections 5
Blower Wheel Dia x Width in. 11 x 7 11 x 8 11 x 8 11 x 10 11 x 10 11 x 11
Air Filtration System
Factory Supplied Media Cabinet
Field Supplied Filter
Filter Used for Certified Watt Data
KGAWF1606UFR
KGAWF1306UFR KGAWF1406UFR
KGAWF1506UFR
Electrical Data 30040 42060 48080 60080 60100 66120
Input Voltage
Volts-Hertz-
Phase
115-60-1
Operating Voltage Range Min-Max 104-127
Maximum Input Amps Amps 7.4 9.1 9.1 11.6 11.7 11.7
Unit Ampacity Amps 10.3 12.4 12.4 15.5 15.6 15.6
Minimum Wire Size
AWG 14 14 14 12 12 12
Maximum Wire Length
@ Minimum Wire Size
Feet 36 30 30 37 36 36
(M) (11.0) (9.1) (9.1) (11.3) (11.0) (11.0)
Maximum Fuse/Ckt Bkr
(Time-Delay Type Recommen-
ded)
Amps 15 15 15 20 20 20
Transformer Capacity
(24vac output)
40 VA
External Control Power
Available
Heating 27.9 VA
Cooling 34.6 VA
Controls 30040 42060 48080 60080 60100 66120
Gas Connection Size 1/2" - NPT
Burners (Monoport) 2 3 4 4 5 6
Gas Valve (Redundant)
Manufac-
turer
White Rogers
Minimum Inlet Gas pressure (in. wc) 4.5
Maximum Inlet Gas pressure (in. wc) 13.6
Gas Conversion Kit - Natural to Propane KGANP50011SP
Gas Conversion Kit - Propane to Natural KGAPN42011SP
Manufactured (Mobile) Home Kit KGAMH0601KIT
Ignition Device Silicon Nitride
Limit Control 165 180 170 200 180 160
Heating Blower Control (Heating Off-Delay) Adjustable: 90, 120, 150, 180 seconds
Cooling Blower Control (Time Delay Relay) 90 seconds
Communication System none
Thermostat Connections Com 24V, R, W, G, Y/Y2, DHUM, Y1
Accessory Connections EAC (115vac); HUM (24vac); 1-stg AC (via Y/Y2)
