WAS TE L INE CONNECTION
If the condensate line is to be connected to a waste (sewer) line, an
open trap must be installed ahead of the waste line to prevent
escape of sewer gases (See Fig. 9 ).
A10216
Fig. 9 -- Condensate Drain to Waste Line
EXPLOSION HAZARD
Failure to follow this warning could result in personal injury
or death.
Provide trap with air gap in drain line when connecting to
waste (sewer) line.
!
