186CNV / 284ANV: Service Manual

Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.

A200191

Fig. 22 – 2/3T VFD Connections

VFDcontrolrelay

andLED

Fanmotorconnections

VFDtoPCMcomm

connection

DC+,DC‐terminals

Fanmotorfuse CompressorUVW

connections

Reactorconnection

HPSconnection(non

replaceablefuseis

directlyabove)

VFDmainpower

relay.Terminals

arenotused.
