13
Table 6 -- ELECTRIC HEAT -- ELECTRICAL DATA 3 -- 6 TONS (CONT)
UNIT
V --- P H --- H Z
IFM TYPE
ELECTRIC HEATER
PART NUMBER
CRHEATERXXXXXX
NOMINAL
POWER
(kW)
APPLICATION
POWER
(kW)
SINGLE POINT OR JUNCTION KIT PART NUMBER
CRSINGLE***A00
NO C.O. or UNPWRD C.O. w/PWRD C.O.
NO P.E. w/ P.E. (pwrd fr/unit) NO P.E. w/ P.E. (pwrd fr/unit)
558J*05
208/230---1--- 60
STD
101A00 4.4 3.3/4.0 --- --- --- ---
103B00 8.7 6.5/8.0 --- --- --- ---
102A00,102A00 13.0 9.8/11.9 040 040 040 040
103B00,103B00 17.4 13.1/16.0 040 040 040 040
104B00,104B00 21.0 15.8/19.3 040 040 040 040
MED
101A00 4.4 3.3/4.0 --- --- --- ---
103B00 8.7 6.5/8.0 --- --- --- ---
102A00,102A00 13.0 9.8/11.9 040 040 040 040
103B00,103B00 17.4 13.1/16.0 040 040 040 040
104B00,104B00 21.0 15.8/19.3 040 040 040 040
208/230---3--- 60
STD
102A00 6.5 4.9/6.0 --- --- --- ---
103B00 8.7 6.5/8.0 --- --- --- ---
105A00 16.0 12.0/14.7 --- --- 038 038
104B00,104B00 21.0 15.8/19.3 038 038 038 038
MED
102A00 6.5 4.9/6.0 --- --- --- ---
103B00 8.7 6.5/8.0 --- --- --- ---
105A00 16.0 12.0/14.7 --- --- 038 038
104B00,104B00 21.0 15.8/19.3 038 038 038 038
HIGH
102A00 6.5 4.9/6.0 --- --- --- ---
103B00 8.7 6.5/8.0 --- --- --- ---
105A00 16.0 12.0/14.7 --- --- 038 038
104B00,104B00 21.0 15.8/19.3 038 038 038 038
4 6 0 --- 3 --- 6 0
STD
106A00 6.0 5.5 --- --- --- ---
108A00 11.5 10.6 --- --- --- ---
109A00 14.0 12.9 --- --- --- ---
108A00,108A00 23.0 21.1 --- --- --- ---
MED
106A00 6.0 5.5 --- --- --- ---
108A00 11.5 10.6 --- --- --- ---
109A00 14.0 12.9 --- --- --- ---
108A00,108A00 23.0 21.1 --- --- --- ---
HIGH
106A00 6.0 5.5 --- --- --- ---
108A00 11.5 10.6 --- --- --- ---
109A00 14.0 12.9 --- --- --- ---
108A00,108A00 23.0 21.1 --- --- --- ---
LEGEND:
CO --- Convenient outlet
DISC --- Disconnect
FLA --- Full load amps
IFM --- Indoor fan motor
LRA --- Locked rotor amps
MCA --- Minimum circuit amps
MOCP --- Maximum over current protection
P E --- Po w e r e x h a u st
UNPWRD CO --- Unpowered convenient outlet
558J
