Bryant LEGACY 558J User Manual

35
ELECTRICAL INFORMATION (CONT)
Table 30 – 558J*06 5 TONS
V --- P H --- H Z
VOLTAGE
RANGE
COMP (ea) OFM (ea) IFM
RLA LRA WATTS FLA TYPE
Max
WATTS
Max
AMP Draw
EFF at Full Load FLA
MIN MAX
2 0 8 --- 1 --- 6 0 187 253 26.2 134 325 1.5
Std Static 1000 5.1 70% 4.9
Med Static 1850 7.4 78% 7.0
2 3 0 --- 1 --- 6 0 187 253 26.2 134 325 1.5
Std Static 1000 5.1 70% 4.9
Med Static 1850 7.4 78% 7.0
2 0 8 --- 3 --- 6 0 187 253 15.6 110 325 1.5
Std Static 1000 5.1 70% 4.9
Med Static 2120 5.5 80% 5.2
High Static 2615 7.9 81% 7.5
2 3 0 --- 3 --- 6 0 187 253 15.6 110 325 1.5
Std Static 1000 5.1 70% 4.9
Med Static 2120 5.5 80% 5.2
High Static 2615 7.9 81% 7.5
4 6 0 --- 3 --- 6 0 414 506 7.7 52 325 0.8
Std Static 2120 2.7 80% 2.6
Med Static 2615 3.6 81% 3.4
High Static 2615 3.6 81% 3.4
5 7 5 --- 3 --- 6 0 518 633 5.8 39 325 0.6
Std Static 2120 2.1 80% 2.0
Med Static 3775 2.9 81% 2.8
High Static 3775 2.9 81% 2.8
Table 31 – 558J*07 6 TONS
V --- P H --- H Z
VOLTAGE
RANGE
COMP (ea) OFM (ea) IFM
RLA LRA WATTS FLA TYPE
Max
WATTS
Max
AMP Draw
EFF at Full Load FLA
MIN MAX
2 0 8 --- 3 --- 6 0 187 253 19.0 12 325 1.5
Std Static 2120 5.5 80% 5.2
Med Static 2615 7.9 81% 7.5
High Static 3775 10.7 81% 10.2
2 3 0 --- 3 --- 6 0 187 253 19.0 12 325 1.5
Std Static 2120 5.5 80% 5.2
Med Static 2615 7.9 81% 7.5
High Static 3775 10.7 81% 10.2
4 6 0 --- 3 --- 6 0 414 506 9.7 62 325 0.8
Std Static 2120 2.7 80% 2.6
Med Static 2615 3.6 81% 3.4
High Static 3775 5.0 81% 4.8
5 7 5 --- 3 --- 6 0 518 633 7.4 50 325 0.6
Std Static 2120 2.1 80% 2.0
Med Static 3775 2.9 81% 2.8
High Static 3775 2.9 81% 2.8
