ELECTRICAL INFORMATION
Table 28 – 558J*04 3 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (ea) OFM (ea) IFM
RLA LRA WATTS FLA TYPE
Max
WATTS
Max
AMP Draw
EFF at Full Load FLA
MIN MAX
2 0 8 --- 1 --- 6 0 187 253 16.6 79 325 1.5
Std Static 1000 5.1 70% 4.9
Med Static 1000 5.1 70% 4.9
2 3 0 --- 1 --- 6 0 187 253 16.6 79 325 1.5
Std Static 1000 5.1 70% 4.9
Med Static 1000 5.1 70% 4.9
2 0 8 --- 3 --- 6 0 187 253 10.4 73 325 1.5
Std Static 1000 5.1 70% 4.9
Med Static 1000 5.1 70% 4.9
High Static 2120 5.5 80% 5.2
2 3 0 --- 3 --- 6 0 187 253 10.4 73 325 1.5
Std Static 1000 5.1 70% 4.9
Med Static 1000 5.1 70% 4.9
High Static 2120 5.5 80% 5.2
4 6 0 --- 3 --- 6 0 414 506 5.8 38 325 0.8
Std Static 1000 2.2 70% 2.1
Med Static 2120 2.7 80% 2.6
High Static 2120 2.7 80% 2.6
5 7 5 --- 3 --- 6 0 518 633 3.8 37 325 0.6
Std Static 1000 2.0 71% 1.9
Med Static 2120 2.1 80% 2.0
High Static 2120 2.1 80% 2.0
Table 29 – 558J*05 4 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (ea) OFM (ea) IFM
RLA LRA WATTS FLA TYPE
Max
WATTS
Max
AMP Draw
EFF at Full Load FLA
MIN MAX
2 0 8 --- 1 --- 6 0 187 253 21.8 117 325 1.5
Std Static 1000 5.1 70% 4.9
Med Static 1850 7.4 78% 7.0
2 3 0 --- 1 --- 6 0 187 253 21.8 117 325 1.5
Std Static 1000 5.1 70% 4.9
Med Static 1850 7.4 78% 7.0
2 0 8 --- 3 --- 6 0 187 253 13.7 83 325 1.5
Std Static 1000 5.1 70% 4.9
Med Static 1000 5.1 70% 4.9
High Static 2120 5.5 80% 5.2
2 3 0 --- 3 --- 6 0 187 253 13.7 83 325 1.5
Std Static 1000 5.1 70% 4.9
Med Static 1000 5.1 70% 4.9
High Static 2120 5.5 80% 5.2
4 6 0 --- 3 --- 6 0 414 506 6.2 41 325 0.8
Std Static 1000 2.2 70% 2.1
Med Static 2120 2.7 80% 2.6
High Static 2120 2.7 80% 2.6
5 7 5 --- 3 --- 6 0 518 633 3.8 37 325 0.6
Std Static 1000 2.0 71% 1.9
Med Static 2120 2.1 80% 2.0
High Static 2120 2.1 80% 2.0
