Table 10 – COOLING CAPACITIES 5 TONS
558J*06
AMBIENT TEMPERATURE
85 95 105 115
EAT (dB) EAT (dB) EAT (dB) EAT (dB)
75 80 85 75 80 85 75 80 85 75 80 85
1500 Cfm
EAT (wB)
58
THC 52.9 52.9 60.0 49.9 49.9 56.6 46.6 46.6 52.9 43.1 43.1 48.9
SHC 45.8 52.9 60.0 43.2 49.9 56.6 40.4 46.6 52.9 37.3 43.1 48.9
62
THC 56.2 56.2 57.6 52.2 52.2 55.7 47.8 47.8 53.5 43.2 43.2 51.0
SHC 41.8 49.7 57.6 39.9 47.8 55.7 37.8 45.6 53.5 35.5 43.2 51.0
67
THC 62.4 62.4 62.4 58.8 58.8 58.8 54.4 54.4 54.4 49.5 49.5 49.5
SHC 34.8 42.8 50.7 33.2 41.2 49.1 31.4 39.3 47.3 29.4 37.3 45.3
72
THC 68.2 68.2 68.2 64.8 64.8 64.8 60.8 60.8 60.8 56.2 56.2 56.2
SHC 27.2 35.2 43.2 25.9 33.9 41.9 24.4 32.4 40.4 22.6 30.6 38.6
76
THC --- 71.1 71.1 --- 69.0 69.0 --- 65.4 65.4 --- 60.9 60.9
SHC --- 28.4 36.6 --- 27.6 35.9 --- 26.3 34.6 --- 24.8 33.0
1750 Cfm
EAT (wB)
58
THC 56.5 56.5 64.0 53.3 53.3 60.4 49.8 49.8 56.5 46.1 46.1 52.3
SHC 48.9 56.5 64.0 46.1 53.3 60.4 43.1 49.8 56.5 39.9 46.1 52.3
62
THC 58.5 58.5 63.4 54.4 54.4 61.3 49.9 49.9 58.9 46.1 46.1 54.4
SHC 45.2 54.3 63.4 43.2 52.2 61.3 41.0 49.9 58.9 37.9 46.1 54.4
67
THC 64.3 64.3 64.3 60.5 60.5 60.5 56.2 56.2 56.2 51.3 51.3 51.3
SHC 36.9 46.1 55.2 35.3 44.5 53.7 33.6 42.8 51.9 31.6 40.8 49.9
72
THC 69.5 69.5 69.5 66.5 66.5 66.5 62.4 62.4 62.4 57.7 57.7 57.7
SHC 27.8 36.9 45.9 26.7 35.9 45.1 25.2 34.5 43.7 23.5 32.8 42.0
76
THC --- 72.2 72.2 --- 70.1 70.1 --- 66.6 66.6 --- --- ---
SHC --- 29.3 38.9 --- 28.6 38.2 --- 27.4 36.8 --- --- ---
2000 Cfm
EAT (wB)
58
THC 59.3 59.3 67.3 56.1 56.1 63.6 52.5 52.5 59.5 48.6 48.6 55.1
SHC 51.4 59.3 67.3 48.6 56.1 63.6 45.4 52.5 59.5 42.1 48.6 55.1
62
THC 60.1 60.1 68.5 56.2 56.2 66.3 52.5 52.5 62.0 48.7 48.7 57.4
SHC 48.1 58.3 68.5 46.2 56.2 66.3 43.1 52.5 62.0 39.9 48.7 57.4
67
THC 65.7 65.7 65.7 61.9 61.9 61.9 57.5 57.5 57.5 52.6 52.6 54.4
SHC 38.8 49.1 59.5 37.3 47.7 58.1 35.6 46.0 56.4 33.6 44.0 54.4
72
THC 70.1 70.1 70.1 67.6 67.6 67.6 63.6 63.6 63.6 58.9 58.9 58.9
SHC 28.3 38.1 48.0 27.4 37.7 48.0 26.0 36.4 46.7 24.3 34.7 45.2
76
THC --- 72.9 72.9 --- 70.8 70.8 --- 67.4 67.4 --- --- ---
SHC --- 30.1 40.7 --- 29.3 39.9 --- 28.2 38.7 --- --- ---
2250 Cfm
EAT (wB)
58
THC 61.5 61.5 69.8 58.4 58.4 66.2 54.8 54.8 62.1 50.8 50.8 57.6
SHC 53.2 61.5 69.8 50.5 58.4 66.2 47.4 54.8 62.1 43.9 50.8 57.6
62
THC 61.6 61.6 72.6 58.4 58.4 68.9 54.8 54.8 64.6 50.8 50.8 59.9
SHC 50.6 61.6 72.6 47.9 58.4 68.9 45.0 54.8 64.6 41.7 50.8 59.9
67
THC 66.8 66.8 66.8 63.0 63.0 63.0 58.5 58.5 60.6 53.6 53.6 58.6
SHC 40.5 52.0 63.4 39.1 50.7 62.3 37.4 49.0 60.6 35.5 47.0 58.6
72
THC 70.8 70.8 70.8 68.5 68.5 68.5 64.5 64.5 64.5 59.8 59.8 59.8
SHC 28.7 39.5 50.2 28.0 39.3 50.5 26.7 38.1 49.6 25.0 36.6 48.1
76
THC --- 73.4 73.4 --- 71.2 71.2 --- 67.9 67.9 --- --- ---
SHC --- 30.7 42.1 --- 30.0 41.4 --- 28.9 40.4 --- --- ---
2500 Cfm
EAT (wB)
58
THC 63.3 63.3 71.8 60.1 60.1 68.2 56.5 56.5 64.1 52.6 52.6 59.6
SHC 54.8 63.3 71.8 52.1 60.1 68.2 49.0 56.5 64.1 45.5 52.6 59.6
62
THC 63.4 63.4 74.7 60.2 60.2 71.0 56.6 56.6 66.7 52.6 52.6 62.1
SHC 52.0 63.4 74.7 49.4 60.2 71.0 46.5 56.6 66.7 43.2 52.6 62.1
67
THC 67.6 67.6 67.6 63.8 63.8 66.2 59.3 59.3 64.6 54.4 54.4 62.5
SHC 42.1 54.6 67.1 40.9 53.5 66.2 39.2 51.9 64.6 37.2 49.8 62.5
72
THC 71.3 71.3 71.3 69.0 69.0 69.0 65.1 65.1 65.1 60.4 60.4 60.4
SHC 29.1 40.7 52.2 28.5 40.7 52.9 27.3 39.7 52.2 25.7 38.3 50.9
76
THC --- 73.8 73.8 --- 71.4 71.4 --- 68.3 68.3 --- --- ---
SHC
--- 31.2 43.3 --- 30.5 42.6 --- 29.6 41.9 --- --- ---
LEGEND:
--- --- D o n o t o p e r a t e
Cfm --- Cubic feet per minute (supply air)
EAT(db) --- Entering air temperature (dry bulb)
EAT(wb) --- Entering air temperature (wet bulb)
N/A --- Not applicable, dry bulb temperature (db) is higher than wet bulb temperature (wb).
SHC --- Sensible heat capacity
THC --- Total heat capacity
