24
Table 12 – STATIC PRESSURE ADDERS (Factory Options and/or Accessories)
CFM 600 800 1000 1250 1500 1750 2000 2250 2500 2750 3000
Vertical Economizer 0.01 0.02 0.035 0.045 0.065 0.08 0.12 0.145 0.175 0.22 0.255
Horizontal Economizer --- --- --- --- --- 0.1 0.125 0.15 0.18 0.225 0.275
CFM 600 900 1200 1400 1600 1800 2000 2200 2400 2600
1ElectricHeaterModule 0.03 0.05 0.07 0.09 0.09 0.1 0.11 0.11 0.12 0.13
2 Electric Heater Modules 0.14 0.15 0.16 0.16 0.16 0.17 0.17 0.17 0.18 0.18
General fan performance notes:
1. Interpolation is permissible . Do not extrapolate.
2. External sta tic pressure is the static pressure differenc e between the return duct and the supply duct plus the static
pressure caused by any FIOPs or accessories.
3. Tabular data accounts for pressure loss due to clean filters, unit casing, and wet coils. Factory options and accessories
may add static pressure losses, as shown in Table 12. Selection software is available, through your salesperson, to help
you select the be st motor/drive combinati on for your applicat ion.
4. The Fan Performance tables offer motor/drive recommendations. In cases when two motor/drive combinations would
work, Bryant recommended the lower horsepower option.
5. For information on the electrical properties of Bryant’s motors, please see the Electrical information section of this
book.
6. For more information on the performance limits of Bryant’s motors, see the application data section of this book.
558J
