45
C08055
Fig. 14 -- Typical Wiring Diagram
NOTES:
Terminal board schematic layout does not match actual terminal board to simplify circuit traces.
Ensure designated j umpers on terminal board are cut when adding smoke detectors, phase loss relay and remote shutdown.
ECONOMIZER NOTES:
1. 620 ohm, 1 watt, 5% resister should be removed only when using differential enthalpy or dry bulb.
2. If a separate f ield---supplied 24V transformer is used for the IAQ sensor power supply, it cannot have the secondary of the transformer grounded.
3. For field --- installed remote minimum position POT, remove black wire jumper between P and P1 and set control minimum position POT to the minimum position.
558J
