Table 9 -- Dry Co il Air Delivery* -- Horizontal and Downflow Discharge --
Unit 574D ----A24--60
UNIT
HEATING
RISE
RANGE
o
F(
o
C)
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
574D(N,P,E )WA36090
35 --- 65
( 1 9 --- 3 6 )
Low Blue
CFM 1234 1168 1093 1021 961 894 825 759 687
Heating
Rise (
o
F)
55 58 62 NA NA NA NA NA NA
Heating
Rise (
o
C)
31 32 35 NA NA NA NA NA NA
M e d ---
Low
Pink
CFM 1290 1223 1154 1090 1027 977 894 828 762
Heating
Rise (
o
F)
53 56 59 62 NA NA NA NA NA
Heating
Rise (
o
C)
29 31 33 35 NA NA NA NA NA
Medium
2
Red
CFM 1354 1290 1226 1158 1102 1046 981 918 843
Heating
Rise (
o
F)
50 53 55 59 62 65 NA NA NA
Heating
Rise (
o
C)
28 29 31 33 34 36 NA NA NA
M e d ---
High
Orange
CFM 1606 1546 1489 1430 1371 1316 1258 1208 1140
Heating
Rise (
o
F)
42 44 46 48 50 52 54 56 60
Heating
Rise (
o
C)
24 24 25 26 28 29 30 31 33
High
1
Black
CFM 1630 1580 1517 1463 1407 1339 1277 1210 1131
Heating
Rise (
o
F)
42 43 45 46 48 51 53 56 60
Heating
Rise (
o
C)
23 24 25 26 27 28 30 31 33
574D(N,P,E )WA42060
25 --- 55
( 1 4 --- 3 1 )
Low
1
Blue
CFM 1295 1234 1182 1126 1075 1016 955 898 857
Heating
Rise (
o
F)
34 36 38 39 41 44 47 49 52
Heating
Rise (
o
C)
19 20 21 22 23 24 26 27 29
M e d ---
Low
Pink
CFM 1345 1282 1235 1194 1140 1095 1027 974 921
Heating
Rise (
o
F)
33 35 36 37 39 41 43 46 48
Heating
Rise (
o
C)
18 19 20 21 22 23 24 25 27
Medium Red
CFM 1505 1452 1413 1358 1323 1282 1234 1169 1130
Heating
Rise (
o
F)
30 31 31 33 34 35 36 38 39
Heating
Rise (
o
C)
16 17 17 18 19 19 20 21 22
M e d ---
High
2
Orange
CFM 1545 1492 1449 1411 1362 1313 1278 1231 1188
Heating
Rise (
o
F)
29 30 31 31 33 34 35 36 37
Heating
Rise (
o
C)
16 17 17 17 18 19 19 20 21
High Black
CFM 1705 1643 1607 1568 1518 1483 1448 1404 1360
Heating
Rise (
o
F)
26 27 28 28 29 30 31 32 33
Heating
Rise (
o
C)
14 15 15 16 16 17 17 18 18
574D(N,P,E )WA42090
35 --- 65
( 1 9 --- 3 6 )
Low Blue
CFM 1295 1234 1182 1126 1075 1016 955 898 857
Heating
Rise (
o
F)
53 55 58 60 63 NA NA NA NA
Heating
Rise (
o
C)
29 31 32 34 35 NA NA NA NA
M e d ---
Low
Pink
CFM 1345 1282 1235 1194 1140 1095 1027 974 921
Heating
Rise (
o
F)
51 53 55 57 60 62 NA NA NA
Heating
Rise (
o
C)
28 29 31 32 33 35 NA NA NA
Medium
1
Red
CFM 1505 1452 1413 1358 1323 1282 1234 1169 1130
Heating
Rise (
o
F)
45 47 48 50 51 53 55 58 60
Heating
Rise (
o
C)
25 26 27 28 29 29 31 32 33
M e d ---
High
2
Orange
CFM 1545 1492 1449 1411 1362 1313 1278 1231 1188
Heating
Rise (
o
F)
44 46 47 48 50 52 53 55 57
Heating
Rise (
o
C)
24 25 26 27 28 29 30 31 32
High Black
CFM 1705 1643 1607 1568 1518 1483 1448 1404 1360
Heating
Rise (
o
F)
40 41 42 43 45 46 47 48 50
Heating
Rise (
o
C)
22 23 24 24 25 25 26 27 28
