41
BELT TENSION METHOD
Requires belt tension gauge that measures tension in belt in units
of lbs force.
Fig. 56 — Belt Drive Motor Mounting
BLOWER PULLEY
V-BELT
MOTOR
PULLEY
MOTOR
MOTOR MOUNTING
PLATE
MOUNTING
BOLTS (4)
