10. Find suitable indoor mounting location for Equipment Control Module, ei-
ther near or on equipment. See Fig. 12.
IMPORTANT NOTE: Equipment Control Module should not be mounted to duct
work or below any other controls or equipment (i.e. humidistat, humidifier, etc.).
A07217
Fig. 12 - Equipment Control Module on Equipment
11. Route wires through rear of Equipment Control Module using either a clear-
ance hole or supplied standoff. See Fig. 13.
