BSi E Series - Basic Components & Layout

10/23
OWNER'S MANUAL & WARRANTY
BSI, LLC 601 East 64th Avenue, Bldg. A, Denver, CO 80229 800.662.9595 sales@bsidesigns.com bsidesigns.com
-
SERIES
AdjustaGuard
5
Fig. 1 shows two glass panels with a center bracket.
BASIC COMPONENTS & LAYOUT
ADJUSTAGUARD BRACKETS
Figure 1
1" Round Post
Glass Panel
CUSTOMER SIDE
SERVER SIDE
Left Bracket
Handle (for angle adjustment)
Right Bracket Glass End Panel
Adjustment Pins
(for height adjustment)
Center Bracket
End Cap
Flange
A. Left AdjustaGuard Bracket B. Center AdjustaGuard Bracket C. Right AdjustaGuard Bracket
