6.5 HF Contour
This control serves a similar purpose as the LF contour, but applied to higher
treble frequencies. The HF contour control allows a subtle change to be made
to the shape of the sound without affecting the previously configured main
equalizer. On a creative note, the HF contour control can be used to breath
‘air’ into an otherwise flat sound, or remove ‘brittleness’ from over bright
signals.
6.6 Output meter
This is a peak reading RMS calibrated meter. Normally when the eq in buttons
are depressed, it measures the signal being sent to the output connector. If the
channel is bypassed (eq in button out), the meter reads the input signal. This
allows accurate matching of the equalized and ‘dry’ signals using the gain
control.
Control operations
